BU4493 800xA 800xA V5.1 | ||
| 3BSE061262R1 | 10 Additional Batch Equipment, 800xA 5.1 | 10 Additional Batch Equipment, 800xA 5.1 |
| 3BSE061253R1 | 10 Structured Data Logs, 800xA 5.1 | 10 Structured Data Logs, 800xA 5.1 |
| 3BSE061263R1 | 100 Additional Batch Equipment, 800xA 5.1 | 100 Additional Batch Equipment, 800xA 5.1 |
| 3BSE061350R1 | 100 Asset Monitors, 800xA 5.1 | 100 Asset Monitors, 800xA 5.1 |
| 3BSE061328R1 | 100 Consolidated History Logs, 800xA 5.1 | 100 Consolidated History Logs, 800xA 5.1 |
| 3BSE061355R1 | 100 Control Loop Asset Monitors, 800xA 5.1 | 100 Control Loop Asset Monitors, 800xA 5.1 |
| 3BSE061269R1 | 100 Dual History Logs, 800xA 5.1 | 100 Dual History Logs, 800xA 5.1 |
| 3BSE061363R1 | 100 FF Device Aspect Objects, 800xA 5.1 | 100 FF Device Aspect Objects, 800xA 5.1 |
| 3BSE061359R1 | 100 HART Device Aspect Objects, 800xA 5.1 | 100 HART Device Aspect Objects, 800xA 5.1 |
| 3BSE061266R1 | 100 History Logs, 800xA 5.1 | 100 History Logs, 800xA 5.1 |
| 3BSE072205R1 | 100 Multisystem Subscriber Redundant Tags | 100 Multisystem Subscriber Redundant Tags |
| 3BSE072204R1 | 100 Multisystem Subscriber Tags | 100 Multisystem Subscriber Tags |
| 3BSE061366R1 | 100 ProfiBus Device Aspect Objects, 800xA 5.1 | 100 ProfiBus Device Aspect Objects, 800xA 5.1 |
| 3BSE061235R1 | 100 tags, non-redundant, 800xA 5.1 | 100 tags, non-redundant, 800xA 5.1 |
| 3BSE061236R1 | 100 tags, redundant, 800xA 5.1 | 100 tags, redundant, 800xA 5.1 |
| 3BSE061351R1 | 1000 Asset Monitors, 800xA 5.1 | 1000 Asset Monitors, 800xA 5.1 |
| 3BSE061329R1 | 1000 Consolidated History Logs, 800xA 5.1 | 1000 Consolidated History Logs, 800xA 5.1 |
| 3BSE061364R1 | 1000 FF Device Aspect Objects, 800xA 5.1 | 1000 FF Device Aspect Objects, 800xA 5.1 |
| 3BSE061360R1 | 1000 HART Device Aspect Objects, 800xA 5.1 | 1000 HART Device Aspect Objects, 800xA 5.1 |
| 3BSE072205R2 | 1000 Multisystem Subscriber Redundant Tags | 1000 Multisystem Subscriber Redundant Tags |
| 3BSE072204R2 | 1000 Multisystem Subscriber Tags | 1000 Multisystem Subscriber Tags |
| 3BSE061367R1 | 1000 ProfiBus Device Aspect Objects, 800xA 5.1 | 1000 ProfiBus Device Aspect Objects, 800xA 5.1 |
| 3BSE061365R1 | 10000 FF Device Aspect Objects, 800xA 5.1 | 10000 FF Device Aspect Objects, 800xA 5.1 |
| 3BSE061361R1 | 10000 HART Device Aspect Objects, 800xA 5.1 | 10000 HART Device Aspect Objects, 800xA 5.1 |
| 3BSE072205R3 | 10000 Multisystem Subscriber Redundant Tags | 10000 Multisystem Subscriber Redundant Tags |
| 3BSE072204R3 | 10000 Multisystem Subscriber Tags | 10000 Multisystem Subscriber Tags |
| 3BSE061368R1 | 10000 ProfiBus Device Aspect Objects, 800xA 5.1 | 10000 ProfiBus Device Aspect Objects, 800xA 5.1 |
| 3BSE061235R3 | 10,000 tags, non-redundant, 800xA 5.1 | 10,000 tags, non-redundant, 800xA 5.1 |
| 3BSE061236R3 | 10,000 tags, redundant, 800xA 5.1 | 10,000 tags, redundant, 800xA 5.1 |
| 3BSE061330R1 | 15000 Consolidated History Logs, 800xA 5.1 | 15000 Consolidated History Logs, 800xA 5.1 |
| 3BSE061271R1 | 15,000 Dual History Logs, 800xA 5.1 | 15,000 Dual History Logs, 800xA 5.1 |
| 3BSE061268R1 | 15,000 History Logs, 800xA 5.1 | 15,000 History Logs, 800xA 5.1 |
| 3BSE061270R1 | 1,000 Dual History Logs, 800xA 5.1 | 1,000 Dual History Logs, 800xA 5.1 |
| 3BSE061267R1 | 1,000 History Logs, 800xA 5.1 | 1,000 History Logs, 800xA 5.1 |
| 3BSE061235R2 | 1,000 tags, non-redundant, 800xA 5.1 | 1,000 tags, non-redundant, 800xA 5.1 |
| 3BSE061236R2 | 1,000 tags, redundant, 800xA 5.1 | 1,000 tags, redundant, 800xA 5.1 |
| 3BSE064667R1 | 300 Control Loop Asset Monitors, 800xA 5.1 | 300 Control Loop Asset Monitors, 800xA 5.1 |
| 3BSE064668R1 | 500 Control Loop Asset Monitors, 800xA 5.1 | 500 Control Loop Asset Monitors, 800xA 5.1 |
| 3BSE061216R512 | 800xA 5.1 DVD Product Box | 800xA 5.1 DVD Product Box |
| 3BSE061234R1 | 800xA Base System | 800xA Base System |
| 3BSE073477R1 | 800xA Dual History Signals - 100 signals NOTE: At pricebook release a TSA was NEEDED for this item. Please, check current need of a TSA in the TSA Database before ordering. | 800xA Dual History Signals - 100 signals NOTE: At pricebook release a TSA was NEEDED for this item. Please, check current need of a TSA in the TSA Database before ordering. |
| 3BSE073477R10 | 800xA Dual History Signals - 1000 signals | 800xA Dual History Signals - 1000 signals |
| 3BSE073477R150 | 800xA Dual History Signals - 15000 signals | 800xA Dual History Signals - 15000 signals |
| 3BSE064565R1 | 800xA for AC 100, 800xA 5.1 | 800xA for AC 100, 800xA 5.1 |
| 3BSE061240R1 | 800xA for AC 870P / Melody, 800xA 5.1 | 800xA for AC 870P / Melody, 800xA 5.1 |
| 3BSE061237R1 | 800xA for Advant Master, 800xA 5.1 | 800xA for Advant Master, 800xA 5.1 |
| 3BSE064196R1 | 800xA for DCI, 800xA 5.1 | 800xA for DCI, 800xA 5.1 |
| 3BSE061239R1 | 800xA for Harmony, 800xA 5.1 | 800xA for Harmony, 800xA 5.1 |
| 3BSE068321R1 | 800xA for Industrial Defender | 800xA for Industrial Defender |
| 3BSE061238R1 | 800xA for MOD 300, 800xA 5.1 | 800xA for MOD 300, 800xA 5.1 |
| 3BSE061244R1 | 800xA for Safeguard, 800xA 5.1 | 800xA for Safeguard, 800xA 5.1 |
| 3BSE067077R1 | 800xA History Signals - Basic 100 signals | 800xA History Signals - Basic 100 signals |
| 3BSE067077R10 | 800xA History Signals - Basic 1000 signals | 800xA History Signals - Basic 1000 signals |
| 3BSE067077R150 | 800xA History Signals - Basic 15000 signals | 800xA History Signals - Basic 15000 signals |
| 3BSE061357R1 | 800xA Maximo Integration, 800xA 5.1 | 800xA Maximo Integration, 800xA 5.1 |
| 3BSE061358R1 | 800xA SAP / Plant Maintenance Integration, 800xA 5.1 | 800xA SAP / Plant Maintenance Integration, 800xA 5.1 |
| 3BSE061341R1 | AC 800M High Integrity and Process Control, 800xA 5.1 | AC 800M High Integrity and Process Control, 800xA 5.1 One fixed license feature per AC 800M controller running both non-SIL and SIL applications in the same controller. |
| 3BSE061249R1 | Advanced Access Control, 800xA 5.0 | Advanced Access Control, 800xA 5.0 |
| 3BSE070904R1 | Advanced Engineering Workplace - Additional Client | Advanced Engineering Workplace - Additional Client |
| 3BSE061354R1 | Advanced Harmony Control System Monitoring, 800xA 5.1 | Advanced Harmony Control System Monitoring, 800xA 5.1 |
| 3BSE070712R1 | Advant Master Central Backup, 800xA 5.1 | Advant Master Central Backup, 800xA 5.1 |
| 3BSE072022R1 | Alarm History and Reports | Alarm History and Reports |
| 3BSE061215R1 | Alarm Operations, 800xA 5.1 | Alarm Operations, 800xA 5.1 |
| 3BSE061248R1 | Audit Trail, 800xA 5.1 | Audit Trail, 800xA 5.1 |
| 3BSE061264R1 | Batch Advanced Phase Templates, 800xA 5.1 | Batch Advanced Phase Templates, 800xA 5.1 |
| 3BSE061258R1 | Batch Base System, 800xA 5.1 | Batch Base System, 800xA 5.1 |
| 3BSE061260R1 | Batch Management Full Client, 800xA 5.1 | Batch Management Full Client, 800xA 5.1 |
| 3BSE061261R1 | Batch Schedule Interface, 800xA 5.1 | Batch Schedule Interface, 800xA 5.1 |
| 3BSE072023R1 | CAD Viewer license | CAD Viewer license |
| 3BSE061252R1 | Calculation Engine, 800xA 5.1 | Calculation Engine, 800xA 5.1 |
| 3BSE067079R1 | Data Access to 800xA History Signals - 100 signals | Data Access to 800xA History Signals - 100 signals |
| 3BSE067079R10 | Data Access to 800xA History Signals - 1000 signals | Data Access to 800xA History Signals - 1000 signals |
| 3BSE067079R150 | Data Access to 800xA History Signals - 15000 signals | Data Access to 800xA History Signals - 15000 signals |
| 3BSE061333R1 | Desktop Trends - Additional Client, 800xA 5.1 | Desktop Trends - Additional Client, 800xA 5.1 |
| 3BSE061250R1 | Digital Signature, 800xA 5.1 | Digital Signature, 800xA 5.1 |
| 3BSE061331R1 | Display Builder for MDI - Additional Client, 800xA 5.1 | Display Builder for MDI - Additional Client, 800xA 5.1 |
| 3BSE064644R1-800xA | Dongle for USB Port | Dongle for USB Port |
| 3BSE061342R1 | Engineering Workplace - Additional Rich Client, 800xA 5.1 | Engineering Workplace - Additional Rich Client, 800xA 5.1 |
| 3BSE061334R1 | Excel Data Access, 800xA 5.1 | Excel Data Access, 800xA 5.1 |
| 3BSE061352R1 | Generic Heat Exchanger Asset Monitor, 800xA 5.1 | Generic Heat Exchanger Asset Monitor, 800xA 5.1 |
| 3BSE061362R1 | HART Multiplexer Connect, 800xA 5.1 | HART Multiplexer Connect, 800xA 5.1 |
| 3BSE061369R1 | IEC 61850-Ed1 Connect, 800xA 5.1 | IEC 61850-Ed1 Connect, 800xA 5.1 |
| 3BSE061265R1 | IM Historian Server, 800xA 5.1 | Basic Historian Server, 800xA 5.1 |
| 3BSE061211R1 | INFI90 Function Code Library for AC 800M, 800xA 5.1 | INFI90 Function Code Library for AC 800M, 800xA 5.1 |
| 3BSE061257R1 | Large Operator Workplace, 800xA 5.1 | Large Operator Workplace, 800xA 5.1 |
| 3BSE061210R1 | MOD 300 CCF Library for AC 800M, 800xA 5.1 | MOD 300 CCF Library for AC 800M, 800xA 5.1 |
| 3BSE061332R1 | Multi-Display Interface (MDI) - Additional Client, 800xA 5.1 | Multi-Display Interface (MDI) - Additional Client, 800xA 5.1 |
| 3BSE061336R1 | ODBC Client Connection, 800xA 5.1 | ODBC Client Connection, 800xA 5.1 |
| 3BSE061335R1 | ODBC Historical Data Server, 800xA 5.1 | ODBC Historical Data Server, 800xA 5.1 |
| 3BSE061246R1 | OLE-DB Real Time Data Client Connection, 800xA 5.1 | OLE-DB Real Time Data Client Connection, 800xA 5.1 |
| 3BSE061245R1 | OPC Client | OPC Client |
| 3BSE061255R1 | Operator Workplace - Additional Client, 800xA 5.1 | Operator Workplace - Additional Client, 800xA 5.1 |
| 3BSE061356R1 | PC, Network and Software Monitoring, 800xA 5.1 | PC, Network and Software Monitoring, 800xA 5.1 |
| 3BSE061243R1 | PLC Connect Dial-Up, 800xA 5.1 | PLC Connect Dial-Up, 800xA 5.1 |
| 3BSE061242R1 | PLC Connect, 800xA 5.1 | PLC Connect, 800xA 5.1 |
| 3BSE061897R1 | PM851 Software License, 800xA 5.1 | PM851 Software License, 800xA 5.1 |
| 3BSE061898R1 | PM856 Software License, 800xA 5.1 | PM856 Software License, 800xA 5.1 |
| 3BSE061899R1 | PM860 Software License, 800xA 5.1 | PM860 Software License, 800xA 5.1 |
| 3BSE061900R1 | PM861/PM861A Software License, 800xA 5.1 | PM861/PM861A Software License, 800xA 5.1 |
| 3BSE061901R1 | PM864/PM864A Software License, 800xA 5.1 | PM864/PM864A Software License, 800xA 5.1 |
| 3BSE061916R1 | PM865 Software License, 800xA 5.1 | PM865 Software License, 800xA 5.1 |
| 3BSE061902R1 | PM866 Software License, 800xA 5.1 | PM866 Software License, 800xA 5.1 |
| 3BSE061903R1 | PM891 Software License, 800xA 5.1 | PM891 Software License, 800xA 5.1 |
| 3BSE061212R1 | Point of Control, 800xA 5.1 | Point of Control, 800xA 5.1 |
| 3BSE061259R1 | Redundant Batch Server Option, 800xA 5.1 | Redundant Batch Server Option, 800xA 5.1 |
| 3BSE061370R1 | Redundant IEC 61850-Ed1 Connect Option, 800xA 5.1 | Redundant IEC 61850-Ed1 Connect Option, 800xA 5.1 |
| 3BSE061345R1 | Reuse Assistant, 800xA 5.1 | Reuse Assistant, 800xA 5.1 |
| 3BSE061353R1 | Shell and Tube Heat Exchanger Asset Monitor, 800xA 5.1 | Shell and Tube Heat Exchanger Asset Monitor, 800xA 5.1 |
| 3BSE070685R1 | Simple Batch Parameter Management - Spreadsheet Scheduling interface desktop version | Simple Batch Parameter Management - Spreadsheet Scheduling interface desktop version |
| 3BSE070899R25 | Smart Client Workplace - Client 1-25 | Smart Client Workplace - Client 1-25 |
| 3BSE070899R50 | Smart Client Workplace - Client 26-50 | Smart Client Workplace - Client 26-50 |
| 3BSE070899R100 | Smart Client Workplace - Client 51-100 | Smart Client Workplace - Client 51-100 |
| 3BSE061251R1 | SMS and e-mail Messaging, 800xA 5.1 | SMS and e-mail Messaging, 800xA 5.1 |
| 3BSE061213R1 | Snapshot Reports, 800xA 5.1 | Snapshot Reports, 800xA 5.1 |
| 3BSE061344R1 | SoftController, 800xA 5.1 | SoftController, 800xA 5.1 |
| 3BSE061110R512 | System 800xA 5.1, 32/64 bit Media only | System 800xA 5.1, 32/64 bit Media only |
| 3BSE070889R1 | TCP Communication Library License | TCP Communication Library License |
| 3BSE070891R1 | UDP Communication Library License | UDP Communication Library License |
| 3BSE070135R1 | Video Client | Video Client |
| 3BSE070134R1 | Video Input Channel | Video Input Channel |
| 3BSE067893R1 | Whitelisting SE46 | Whitelisting SE46 |
| 3BSE067217R1 | Whitelisting Studio SE46 | Whitelisting Studio SE46 |
AC 800M Controller | ||
| 3BSE031155R1 | BC810K02 | BC810K02 CEX-bus Interconnection Unit Including: - BC810, Interconnection Unit, 2 units - TP857, Baseplate, width = 60 mm, 2 units - TK851, Interconnection Cable - TB850, CEX-Bus Terminator, 2 units |
| 3BSE018103R1 | CI853K01 | CI853K01 Dual RS232-C interface Package including: -CI853, Communication Interface -TP853, Baseplate, width = 60 mm |
| 3BSE030220R1 | CI854AK01 | CI854AK01 PROFIBUS DP-V1 Communication interface Package including: - CI854A, Communication Interface - TP854, Baseplate, width = 60 mm |
| 3BSE018106R1-800xA | CI855K01 | CI855K01 MB 300 Dual Ethernet port interface Package including: -CI855, MB300 Interface Module -TP853, Base plate |
| 3BSE026055R1-800xA | CI856K01 | CI856K01 S100 I/O interface Installed on DIN rail. Communication bridge between AC800M and S100 system. Package including: - CI856, Communication Interface - TP856, Baseplate, width = 60mm |
| 3BSE018144R1-800xA | CI857K01 | CI857K01 INSUM Ethernet interface Package including: - CI857, Communication Interface - TP853, Baseplate, width = 60 mm |
| 3BSE018135R1-800xA | CI858K01 | CI858K01 DriveBus Interface Package including: - CI858, Communication Interface - TP858, Baseplate, width = 60 mm |
| 3BSE032444R1 | CI860K01 | CI860K01 FOUNDATION Fieldbus HSE Interface Package including: -CI860, Communication Interface -TP860, Baseplate, width = 60 mm |
| 3BUA000037R1 | CI862K01 | CI862K01 TRIO Interface Kit Package including: - CI862, Communication Interface - TP862, Baseplate, width = 60mm |
| 3BUA000111R1 | CI862K02 | CI862K02 Redundant TRIO Interface Kit with Connection Cable, G1 Compliant |
| 3BSE040795R1 | CI865K01 | CI865K01Communication Interface Module for Satt I/O Package including: - CI865, Communication Interface - TP865, Baseplate, width = 60 mm |
| 3BSE043660R1 | CI867K01 | CI867K01 Modbus TCP Interface Package including: -CI867 , Communication Interface -TP867 , Baseplate, width=60mm |
| 3BSE048845R1 | CI868K01 | CI868K01 IEC61850 Communication interface Package including: -CI868 , Communication Interface -TP867 , Baseplate, width=60mm THIS ITEM IS RESTRICTED TO ABB INTERNAL UNITS ONLY. THIS ITEM NEEDS A TSA TO BE ORDERED. |
| 3BSE056767R1 | CI871K01 | CI871K01 PROFINET IO Communication Interface Package including: - CI871, Communication Interface - TP867, Baseplate width=60mm |
| 3BSE051129R1-800xA | CI872K01 | CI872K01 MOD5 Communication interface |
| 3BSE056899R1 | CI873K01 | CI873K01 Ethernet/IP Communication Interface |
| 3BSE066485R6 | PM851AK01 | PM851AK01 Processor Unit Package including: -PM851, CPU -TP830, Baseplate, width=115 mm -TB850, CEX-bus terminator -TB807, ModuleBus terminator -Battery for memory backup (4943013-6) |
| 3BSE066490R6 | PM856AK01 | PM856AK01 Processor Unit Package including: -PM856, CPU -TP830, Baseplate, width=115 mm -TB850, CEX-bus terminator -TB807, ModuleBus terminator -Battery for memory backup (4943013-6) |
| 3BSE066495R6 | PM860AK01 | PM860AK01 Processor Unit Package including: -PM860, CPU -TP830, Baseplate, width=115 mm -TB850, CEX-bus terminator -TB807, ModuleBus terminator -Battery for memory backup (4943013-6) |
| 3BSE018157R6 | PM861AK01 | PM861AK01 Processor Unit Package including: -PM861A, CPU -TP830, Baseplate, width =115mm -TB850, CEX-bus terminator -TB807, ModuleBus terminator -TB852, RCU-Link terminator -Battery for memory backup (4943013-6) |
| 3BSE018160R6 | PM861AK02 | PM861AK02 Redundant Processor Unit Package including: 2 pcs PM861AK01, Processor unit. 1 pcs TK850, CEX-bus expansion cable. 1 pcs TK851, RCU-Link cable. |
| 3BSE018161R6 | PM864AK01 | PM864AK01 Processor Unit Package including: -PM864A, CPU -TP830, Baseplate, width =115mm -TB850, CEX-bus terminator -TB807, ModuleBus terminator -TB852, RCU-Link terminator -Battery for memory backup (4943013-6) |
| 3BSE018164R6 | PM864AK02 | PM864AK02 Redundant Processor Unit Package including: 2 pcs PM864AK01, Processor unit. 1 pcs TK850, CEX-bus expansion cable. 1 pcs TK851, RCU-Link cable. |
| 3BSE031151R6 | PM865K01 | PM865K01 Processor Unit |
| 3BSE031150R6 | PM865K02 | PM865K02 Redundant Processor Unit |
| 3BSE050198R6 | PM866K01 | PM866K01 Processor Unit Package including: -PM866, CPU -TP830, Baseplate, width =115mm -TB850, CEX-bus terminator -TB807, ModuleBus terminator -TB852, RCU-Link terminator -Battery for memory backup (4943013-6) |
| 3BSE050199R6 | PM866K02 | PM866K02 Redundant Processor Units Package including: 2 pcs PM866K01, Processor unit. 1 pcs TK850, CEX-bus expansion cable. 1 pcs TK851, RCU-Link cable. |
| 3BSE053241R6 | PM891K01 | PM891K01 Processor Unit |
| 3BSE053242R6 | PM891K02 | PM891K02 Redundant Processor Unit |
| 3BSE018172R1-800xA | SB822 | SB822 Rechargeable battery unit External DIN-rail mounted rechargeable battery unit including lithium-ion battery, 24V DC connector and connection cable TK821V020 Width=85 mm Equivalent amount of Lithium metal=0,8g (0,03oz) |
| 3BSE018173R1 | SM811K01 | AC800M controller |
| 3BSC950193R1-800xA | TB850 | TB850 CEX-Bus Terminator With 25-pin DB25P male connector. With screw fixing. A TB850 CEX-Bus terminator must always be installed on the last unit on the CEX bus. |
| 3BSC950194R1-800xA | TB851 | TB851 CEX-Bus Terminator With 25-pin DB25S female connector. With screw fixing. When Communication Interface units are mounted on adjacent DIN rails, they are connected by means of a CEX-Bus extension cable (TK850) and terminated using a TB851 CE |
| 3BSC950263R1-800xA | TB852 | TB852 RCU Link Terminator |
| 3BSE057022R1-800xA | TB853 | TB853 RCU Control Link Terminator |
| 3BSC630049R1-800xA | TC562 | TC562 Short Distance Modem length < 10 km. Point-to-point up to 1 km at 19200 bps. Power 24V d.c Width=55 mm |
| 3BSC630197R1-800xA-M | TK212A | TK212 Tool cable RJ45 to Dsub-9 (female), length 3 m For connection of FS801 and CI840 to PC |
| 3BSC950192R1-800xA | TK850V007 | TK850V007 CEX-Bus Extension Cable Length= 0.7 m Use of TK850V007 needs TK851 as CEX-bus terminator. |
| 3BSC950262R1-800xA | TK851V010 | TK851V010 Connection Cable Length= 1.0 m Used as: - RCU Link Cable - BC810 Interconnection Cable |
| 3BSC950201R1-800xA | TK853V020 | TK853V020 Modem Cable Length 2 m Cable for connection between modem TC562 and TP830 |
| 3BSC950356R1-800xA | TK855 | TK855 RCU Data Link Cable |
| 3BSE057021R1-800xA | TK856 | TK856 RCU Control Link Cable |
| 3BSE049110R1-800xA | CI869K01 AF 100 Communication Interface | CI869K01 AF 100 Communication Interface |
S800IO | ||
| 3BSE020512R1 | AI801 | AI801 Analog input 1x8 ch, 0(4)..20mA, 12bit, single ended, 0.1%, Rated isol. 50V |
| 3BSE008516R1 | AI810 | AI810 Analog input 1x8 ch. 0(4)..20mA, 0..10V, 12Bit, single ended, 0.1%, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830, TU835, TU838. |
| 3BSE052604R1 | AI815 | AI815 Analog Input. Redundant or single 1x8ch. HART. 0(4)..20mA, 0(1)..5V, 12bit, single ended, 0.1%, Rated isol. 50V. Current limited transmitter power distribution. Advanced on-board diagnostics. Use Module Termination Unit TU810, TU812, TU814, TU830 |
| 3BSE008544R1 | AI820 | AI820 Analog input 4x1 ch. +-20mA, 0(4)...20mA, +-10V, +-5V, 0(1)...5V, diff., 50V CMV, 14bit +sign. Rin(curr)250 Ohms, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE036456R1 | AI825 | Analog Input 4x1ch Galv. isol. -20..20mA, 0(4)..20mA, -10..10V, 0(2)..10V, Galvanically isolated channels 14Bit+sign, 0.1%, Rated isol. 250V Use Module Termination Unit TU811, TU813, TU831. |
| 3BSE040662R1 | AI830A | AI830 Analog Input 1x8ch Pt100, Ni100/120, Cu10, R, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE051306R1 | AI835A | AI835 Analog input 8 ch. Thermocouple/mV Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE028925R1 | AI843 | AI843 Analog Input , Redundant or Single 1x8chTermocouple/mV Rated isol. 50V Use Modules Termination Unit TU830, TU842, TU843 |
| 3BSE023675R1 | AI845 | AI845 Analog Input. Redundant or single 1x8ch. HART Communications. 0(4)..20mA, 0(1)..5V, 12bit, single ended, 0.1%, Rated isol. 50V. Current limited transmitter power distribution. Advanced on-board diagnostics. Use Module Termination Unit TU810, TU81 |
| 3BSE039293R1 | AI880A | AI880A High Integrity Analog Input. Single or Redundant. HART 4..20mA, 8 ch. Current input. HART communication. Certified for SIL3. Requires configuration according to Safety Manual. |
| 3BSC690071R1-800xA | AI890 | AI890 Analog Input 1x8 ch with Intrinsic Safety Interface 0 (4)...20mA single ended 0,1%. Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSC690141R1-800xA | AI893 | AI893 Analog Input 8 ch. Temp. measuring. Intrinsic Safety Interf. G3 compliant. For TC and RTD sensors. Rated isol. 50V. Use Module Termination Unit TU890 or TU891. |
| 3BSC690086R1-800xA | AI895 | Analog Input 1x8 ch with Intrinsic Safety and HART Int |
| 3BSE020514R1 | AO801 | AO801 Analog output 1x8 ch, 0(4)...20mA, 12 bit, RLmax 850 Ohm, Rated isol. 50V |
| 3BSE038415R1 | AO810V2 | AO810 Analog output 1x8 ch, 0(4)...20mA, 14 bit, RLmax 500/950 Ohms, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE052605R1 | AO815 | AO815 Analog Output. Redundant or single 1x8ch. HART. 4..20mA, 12bit, 0.1%, RLmax 750 ohm, Rated isol. 50V. Advanced on-board diagnostics. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833, TU842, TU843. |
| 3BSE008546R1 | AO820 | AO820 Analog Output 4x1 ch, +-20mA, 0(4)...20mA, +-10V, 12bit+sign. Indiv. isol. ch. RL max 500 Ohms, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE045584R1 | AO845A | AO845A Analog Output Redundant or single 1x8ch HART 4..20mA, 12bit, 0.1%, RLmax 750 ohm, Rated isol. 50V. Advanced on-board diagnostics. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833, TU842, TU843. |
| 3BSC690072R1-800xA | AO890 | AO890 Analog Output 1x8 ch with Intrinsic Safety Interface 0 (4)...20mA 0,1%. RL max 750 ohm Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSC690087R1-800xA | AO895 | AO895 Analog Output 1x8 ch with Intrinsic Safety and HART Interf. G3 compliant. 4...20mA 0,1%. RL max 750 ohm Rated isol. 50V. Use Module Termination Unit TU890 or TU891. |
| 3BSE022366R1 | CI801 | CI801 ProfiBus FCI S800 Communication Interface Including: 1 pcs Power Supply Connector 1 pcs TB807 Modulebus Terminator The basic system software loaded in CI801 does not support the following I/O modules: DI830, DI831, DI885, AI880, DI880 an |
| 3BSE038540R1300-800xA | CI801KIT | CI801 Engineering kit Including: 1 pce Diskette with GSD file and Release Note. 1 pce Reference Manual Memory Maps for CI801. |
| 3BSE020520R1 | CI810B | CI810B AF100 Field Comm. Interface |
| 3BSE025255R1 | CI820V1 | CI820V1 S800 Redundant FCI |
| 3BSE041882R1 | CI840A | CI840 Profibus Communications Interface. For 1+1 redundant operation. Two CI840 and one TU847 or one TU846 must be ordered. The basic system software loaded in CI840 does not support the following I/O modules: DI830, DI831, DI885, AI880, DI880, DO880 a |
| 3BSE031694R4000-800xA | CI840KIT | CI840 Engineering Kit Including: 1 pce Diskette with GSD file and Release Note. 1 pce Reference Manual Memory Maps for CI840 |
| 3BSE020508R1 | DI801 | DI801 Digital Input 24V d.c. 1x16 ch, Rated isol.50V |
| 3BSE022360R1 | DI802 | DI802 Digital Input 120V a.c./d.c., 8x1ch. Rated isol. 250V. |
| 3BSE022362R1 | DI803 | DI803 Digital Input 230V a.c./d.c., 8x1ch. Rated isol. 250V. |
| 3BSE008508R1 | DI810 | DI810 Digital Input 24V d.c. 2x8 ch. Rated isolation 50V. Use Module Termination Unit TU810, TU812, TU814, TU830, TU838. |
| 3BSE008552R1 | DI811 | DI811 2x8 ch 48V Digital input 48Vd.c. 2x8ch, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830, TU838. |
| 3BUR001454R1 | DI814 | DI814 Digital Input 24V d.c. Current Source 2x8 ch, Rated isol. 50V. Use Module Termination Unit TU810, TU812, TU814, TU830, TU838. |
| 3BSE069052R1 | DI818 | 2x16 ch, Rated isol. 50V, Use Module Termination Unit TU818, TU819, TU830 |
| 3BSE008512R1 | DI820 | DI820 Digital Input, 120 V a.c. 8x1 ch,Rated isol. 250V |
| 3BSE008550R1 | DI821 | DI821 Digital Input 230V a.c. 8x1 ch, Rated isol. 250V Use Module Termination Unit TU811, TU831. |
| 3BSE036373R1 | DI825 | Digital Input 1x8ch , 125V d.c. SOE Individually Isolated channels, Rated isol. 250V. Use Module Termination Unit TU811, TU813, TU831. |
| 3BSE069054R1 | DI828 | DI828 Digital Input, 120V a.c./d.c. 16 ch 16x1 ch, Rated isol. 250V, Use Module Termination Unit TU851. Special delivery conditions may apply, please see 3BSE073674 in ABB Library. |
| 3BSE013210R1 | DI830 | DI830 Digital Input 24V d.c. SOE 2x8 ch, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830, TU838. |
| 3BSE013212R1 | DI831 | DI831 Digital Input 48V d.c.,SOE 2x8 ch, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830, TU838. |
| 3BSE020836R1 | DI840 | DI840 Digital Input. Redundant or single, 24V d.c., 1x16ch. Advanced On-Board diagnostics. Rated isol. 50V. Use Module Termination Unit TU810, TU812, TU814, TU830, TU838, TU842, TU843 |
| 3BSE028586R1 | DI880 | DI880 High Integrity Digital Input Single or Redundant |
| 3BSE013088R1-800xA | DI885 | DI885 Digital Input 24/48V d.c.,SOE 1x8 ch, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSC690073R1-800xA | DI890 | DI890 Digital Input 8x1 ch with Intrinsic Safety Interface Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSE020510R1 | DO801 | DO801 Digital Output 16ch. 24V d.c. 0.5A. Short circuit proof, Rated isol. 50V |
| 3BSE022364R1 | DO802 | DO802 Digital Output, Relay. Normal open 8x1 ch, 24-230V, a.c. Rated isol. 250V |
| 3BSE008510R1 | DO810 | DO810 Digital Output 24 V d.c. 2x8 ch 0.5A, Short circuit proof, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BUR001455R1 | DO814 | DO814 Digital Output current sinking 2x8 ch 0,5A , shortcut circuit proof, Rated isol.50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE013258R1 | DO815 | DO815 Digital Output 24V d.c 2x4 ch, 2.0A short circuit proof. Rated isolation 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE069053R1 | DO818 | Digital Output 24V d.c. 32 ch 2x16 ch, 0.5A, Short circuit proof, Rated isol. 50V, Use Module Termination Unit TU818, TU819, TU830 |
| 3BSE008514R1 | DO820 | DO820 Digital Output, Relay. Normal open 8x1 ch, 24-230V a.c. 3A, cos phi>0.4, d.c. 42W, Rated isol. 250V Use Module Termination Unit TU811, TU831, TU836, TU837. |
| 3BSE013250R1 | DO821 | DO821 Digital Output, Relay. Normal closed 8x1 ch, 24-230V a.c. 3A, cos phi>0.4, d.c. 42W, Rated isol.250V |
| 3BSE069055R1 | DO828 | DO828 Digital Output, Relay Normally Open, 16 ch 16x1 ch, 5-250V a.c and 5-125V d.c, max 2A, Rated isol. 250V, Use Module Termination Unit TU851. Special delivery conditions may apply, please see 3BSE073674 in ABB Library. |
| 3BSE020838R1 | DO840 | DO840 Digital Output. Redundant or single. 24V d.c., 0.5A. 2x8 ch. Advanced On-board diagnostics. Rated isol. 50V. Use Module Termination Unit TU810, TU812, TU814, TU830, TU842, TU843. |
| 3BSE028602R1 | DO880 | DO880 High Integrity Digital Output. Single or Redundant. |
| 3BSC690074R1-800xA | DO890 | DO890 Digital Output 4x1 ch with Intrinsic Safety Interface Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSE013228R1 | DP820 | DP820 Pulse Counter RS-422, Current, 5V, (12V), 24V 2 ch bidirectional pulse counters and frequency measurement. 1,5MHz Rated isol 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSE028926R1 | DP840 | DP840 Pulse Counter or Frequency Measurement Module. Redundant or single. 1x8ch, 20kHz. Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830, TU842, TU843, TU844, TU845 |
| 3BSE038407R1-800xA | FS801K01 | FS801K01 firmware upgrade tool |
| 3BSC610064R1-800xA | SD831 | SD831 Power Supply Device Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 3A. If redundant power application is required connect to SS8XX. Voting unit. Width=35mm. DIN rail mounted. |
| 3BSC610065R1-800xA | SD832 | SD832 Power Supply Device Input a.c. 100-120/200-240 V. Output d.c. 24 V 5A, auto-select input. If redundant power application is required connect to SD8XX. Voting unit. Width=35mm. DIN rail mounted. |
| 3BSC610066R1-800xA | SD833 | SD833 Power Supply Device Input a.c. 100-120/200-240 V, auto-select input. Output d.c. 24 V 10A. If redundant power application is required connect to SD8XX. Voting unit. Width=60mm. DIN rail mounted. |
| 3BSC610067R1-800xA | SD834 | SD834 Power Supply Device Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 20A. If redundant power application is required connect to SS8XX. Voting unit. Width=85mm. DIN rail mounted. |
| 3BSE038226R1 | SS823 | SS823 |
| 3BSC610068R1-800xA | SS832 | SS832 Voting Device Input d.c. 24 V. Dual 24 V to single 24 V, 2x10A. Width=35mm. DIN rail mounted. |
| 3BSE008534R1-800xA | TB805 | TB805 Bus Outlet Modulebus extension cable adaptor D-sub 25, female One requried per extension cable TK801 |
| 3BSE008536R1-800xA | TB806 | TB806 Bus Inlet Modulebus extension cable adaptor D-sub 25, male One requried per extension cable TK801 |
| 3BSE008538R1-800xA | TB807 | Modulebus terminator |
| 3BSE008560R1 | TB810 | Modulebus Optical Port |
| 3BSE008568R1 | TB811 | TB811 Modulebus Optical Port Used together with CI810, CI820, CI830 Used with ABB Drives equipment. (5 Mbits driver) |
| 3BSE013204R1 | TB815 | TB815 Interconnection Unit Including: 1 pce TB807 Modulebus Terminator Used for interconnection of two CI820. |
| 3BSE013208R1 | TB820V2 | TB820V2 Modulebus Cluster Modem Optical cluster modem for non redundant operation. Including: 1 pce Power Supply Connector 1 pce TB807 Modulebus Terminator |
| 3BSE036634R1 | TB825 | TB825 Optical Media Conv. Short to long distance optical fiber conversion. For modulebus communication up to 1000m. |
| 3BSE061637R1 | TB826 | TB826 Long range optical media converter |
| 3BSE037760R1 | TB840A | TB840A Modulebus Cluster Modem Optical cluster modem for 1+1 redundant operation. |
| 3BSE022464R1-800xA | TB842 | TB842 Modulebus Optical Port Used together with CI801 and CI840, connected via TB806 or TB846. 10 Mbits driver. |
| 3BSE021437R1-800xA | TB845 | TB845, Dual Modulebus outlet Modulebus extension cable adaptor two D-sub, female. Two TK801 cables for redundancy |
| 3BSE021439R1-800xA | TB846 | TB846, Dual Modulebus inlet Modulebus extension cable adaptor two D-sub, male. Two TK801 cables for redundancy |
| 3BSC630197R1-800xA | TK212A | TK212 Tool cable RJ45 to Dsub-9 (female), length 3 m For connection of FS801 and CI840 to PC |
| 3BSC950004R1 | TK527V030 | TK527V030 Interface cable, L = 3 m. DE9 pin to DE9 socket. |
| 3BSC950089R1-800xA | TK801V003 | TK801V003 Cable. Modulebus Extension Shielded Cable 0.3m D-sub 25, male-female.G3 compliant |
| 3BSC950089R2-800xA | TK801V006 | TK801V006 Cable. Modulebus Extension Shielded Cable 0.6m D-sub 25, male-female. G3 compliant |
| 3BSC950089R3-800xA | TK801V012 | TK801V012 Cable. Modulebus Extension Shielded Cable 1.2m D-sub 25, male-female. G3 compliant. |
| 3BSC950107R1-800xA | TK811V015 | TK811V015 POF Cable, 1.5m, Duplex L=1.5m latching duplex connector Duplex plastic fibre |
| 3BSC950107R2-800xA | TK811V050 | TK811V050 POF Cable, 5m, Duplex L=5m latching duplex connector Duplex plastic fibre |
| 3BSC950107R3-800xA | TK811V150 | TK811V150 POF Cable, 15m, Duplex L=15m latching duplex connector Duplex plastic fibre |
| 3BSC950118R1-800xA | TK812V015 | TK812V015 POF Cable, 1.5m, Simplex L=1.5m latching connector Simplex plastic fibre |
| 3BSC950118R2-800xA | TK812V050 | TK812V050 POF Cable, 5m, Simplex L=5.0m latching connector Simplex plastic fibre |
| 3BSC950118R3-800xA | TK812V150 | TK812V150 POF Cable, 15m, Simplex L=15m latching connector Simplex plastic fibre |
| 3BSE035990R1-800xA | TU805K01 | TU805K01 Termination Units for two or three wire connection of DI801 and DO801 Include 10 pcs of Termination Unit TU805 |
| 3BSE039025R1-800xA | TU807 | Termination Unit for TB840/TB840A Support for single modulebus I/O. Including:1 pcs TB807 |
| 3BSE013230R1-800xA | TU810V1 | TU810V1 Compact Module Termination Unit, MTU, 50V. 2x8 signal terminals, rated isol. 50V. |
| 3BSE013231R1-800xA | TU811V1 | TU811V1 Compact Module Termination Unit, MTU, 250V. 1x8 signal terminals, rated isol. 250V. |
| 3BSE013232R1-800xA | TU812V1 | TU812V1 Compact Module Termination Unit, MTU, 50V. With 25 pin D-sub connector, rated isol. 50V. D-sub (female) connector is not enclosed. |
| 3BSE036714R1-800xA | TU813 | Compact Module Termination Unit, MTU, 250V 2x8 Signal terminals, Rated isol. 250V Detachable (pluggable) connectors are not enclosed. |
| 3BSE013233R1-800xA | TU814V1 | TU814V1 Compact Module Termination Unit, MTU, 50V. 2x8 Signal terminals, rated isol. 50V. Detachable (pluggable) connectors are not enclosed. |
| 3BSE069209R1-800xA | TU818 | TU818 Compact Module Termination Unit, MTU, 50V 1x32 (and 2x16) signal terminals, Rated isol. 50V |
| 3BSE068891R1-800xA | TU819 | Compact Module Termination Unit, MTU, 50V. With 2x25 pin D-sub connector, Rated isol. 50V, D-sub (female) connector is not enclosed |
| 3BSE013234R1-800xA | TU830V1 | TU830V1 Extended Module Termination Unit, MTU, 50V. 2x16 signal terminals, rated isol. 50V. |
| 3BSE013235R1-800xA | TU831V1 | TU831V1 Extended Module Termination Unit, MTU, 250V. 2x8 signal terminals, rated isol. 250V. |
| 3BSE038726R1-800xA | TU833 | TU833 Extended Module Termination Unit, MTU, 50V. 2x16 signal terminals, Rated isol. 50V. Spring-cage terminals. |
| 3BSE040364R1 | TU834 | TU834 Extended Module Termination Unit, MTU 50V |
| 3BSE013236R1-800xA | TU835V1 | TU835V1 Extended Module Termination Unit, MTU, 50V. 8 fused power outlets, 8 signal terminals, rated isol. 50V. |
| 3BSE013237R1-800xA | TU836V1 | TU836V1 Extended Module Termination Unit, MTU, 250V. 2x4 fused signals, 2x4 return terminals, 2x2 L 2x2N terminals, rated isol. 250V. |
| 3BSE013238R1-800xA | TU837V1 | TU837V1 Extended Module Termination Unit, MTU, 250V. 8x1 fused isol. signals, 8x1 L terminals, 2x6 N terminals, rated isol. 250V. |
| 3BSE008572R1-800xA | TU838 | TU838 Extended Module Termination Unit, MTU, 50V. 2x4 fused transducer power outlets, 16 signal terminals, 2x4 return terminals, 2x2 L+, 2x2 L- terminals, rated isol. 50V. Module is mounted horizontally. |
| 3BSE046966R1-800xA | TU839 | TU839 Extended Module Termination Unit, 250V 2x8 signal terminals 2x4 fused sensor power Rated isol. 250V |
| 3BSE020846R1-800xA | TU840 | TU840 Termination Unit for 1+1 TB840 Support for redundant I/O Including: 1 pce Power Supply Connector 2 pce TB807 Modulebus Terminator |
| 3BSE020848R1-800xA | TU841 | Termination unit for 1+1 TB840 Support for non-redund |
| 3BSE020850R1-800xA | TU842 | MTU, for redundant AO/DI/DO84X, Horizontal mounted |
| 3BSE021443R1-800xA | TU843 | MTU, for redundant AO/DI/DO84X, Vertical mounted |
| 3BSE021445R1-800xA | TU844 | MTU, for redundant AI845, Horizontal mounted |
| 3BSE021447R1-800xA | TU845 | MTU, for redundant AI845, Vertical mounted |
| 3BSE022460R1-800xA | TU846 | Mounting unit for 1+1 TU847,redundant I/O |
| 3BSE022462R1-800xA | TU847 | Mounting unit for 1+1 TU847,non-redundant I/O |
| 3BSE042558R1-800xA | TU848 | TU848, MTU with individual power supply for red. TB840/TB840A. Support for dual modulebus. Including: 2 pcs TB807 |
| 3BSE042560R1-800xA | TU849 | TU849, MTU with individual power supply for red. TB840/TB840A. Support for single modulebus Including: 1 pcs TB807 |
| 3BSE050930R1-800xA | TU850 | TU850 Extended Module Termination Unit, MTU, 50V 2x8 signal terminals and 2x8 disconnetable current limited sensor/transmitter outlet power terminals. Rated isol. 50V. |
| 3BSE068782R1-800xA | TU851 | TU851 Extended Module Termination Unit, MTU, 250V |
| 3BSE069964R1-800xA | TU852 | TU852 Module Termination Unit, MTU, for redundant applications, 50V |
| 3BSE069966R1-800xA | TU854 | TU854 Module Termination Unit, MTU, for redundant applications, 50V |
| 3BSC690075R1-800xA | TU890 | TU890 Module Termination Unit for Intrinsic Safety applications 3x9 signal terminals Rated isol. 50V. Including wiring separator. |
| 3BSC840157R1-800xA | TU891 | TU891 Module Termination Unit for non Intrinsic Safety applications |
| 3BSE023607R1-800xA | TY801K01 | TY801K01 8pcs Shunt Stick TY801 125 + 125 ohms shunt. Used for AI845 and AI880 on TU844, TU845 |
| 3BSE033670R1-800xA | TY804K01 | TY804K01 8pcs Shunt Stick TY804 1000 ohms shunt. Used for DP840 on TU844, TU845 |
| 3BSE056980R1-800xA | TY820K01 | TY820K01 10pcs Temperature Sensor TY820 |
Automation sentinel-Maintain | ||
| 2PAA108142R3(1) | Automation Sentinel-Maintain(for 1 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(10) | Automation Sentinel-Maintain(for 10 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(11) | Automation Sentinel-Maintain(for 11 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(2) | Automation Sentinel-Maintain(for 2 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(3) | Automation Sentinel-Maintain(for 3 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(4) | Automation Sentinel-Maintain(for 4 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(5) | Automation Sentinel-Maintain(for 5 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(6) | Automation Sentinel-Maintain(for 6 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(7) | Automation Sentinel-Maintain(for 7 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(8) | Automation Sentinel-Maintain(for 8 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
| 2PAA108142R3(9) | Automation Sentinel-Maintain(for 9 digivis) | The Maintain level provides a set of lifecycle support services and deliverables including software maintenance of the current system software version. |
Compact Product Suite AC 800M Controller | ||
| 3BSE031155R2 | BC810K02-eA | BC810K02-eA CEX-bus Interconnection Unit |
| 3BSE071500R2 | BC820K02-eA | BC820K02-eA RCU-Link and CEX-Bus Interconnection Units |
| 3BSE018103R2 | CI853K01 | CI853K01-eA Dual RS232-C interface |
| 3BSE069449R2 | CI854BK01-eA | CI854BK01-eA Profibus Communication Interface |
| 3BSE018106R1 | CI855K01 | CI855K01 MB 300 Dual Ethernet port interface Package including: -CI855, MB300 Interface Module -TP853, Base plate |
| 3BSE026055R1 | CI856K01 | CI856K01 S100 I/O interface Installed on DIN rail. Communication bridge between AC800M and S100 system. Package including: - CI856, Communication Interface - TP856, Baseplate, width = 60mm |
| 3BSE018144R1 | CI857K01 | CI857K01 INSUM Ethernet interface Package including: - CI857, Communication Interface - TP853, Baseplate, width = 60 mm |
| 3BSE018135R1 | CI858K01 | CI858K01 DriveBus Interface Package including: - CI858, Communication Interface - TP858, Baseplate, width = 60 mm |
| 3BSE040795R2 | CI865K01-eA | E090 - SS832 Voting Device, G2 Compliant Input d.c. 24 V. Dual 24 V to single 24 V, 2x10A. Width=35mm. DIN rail mounted. |
| 3BSE043660R2 | CI867K01--eA | CI867K01-eA Modbus TCP Interface |
| 3BSE048845R2 | CI868K01-eA | CI868K01-eA IEC61850-Ed1 (Edition 1) Communication Interface |
| 3BSE049110R1 | CI869K01 | CI869K01 AF 100 Communication Interface |
| 3BSE056767R2 | CI871K01-eA | CI871K01-eA PROFINET IO Communication Interface |
| 3BSE051129R1 | CI872K01 | CI872K01 MOD5 Communication interface |
| 3BSE056899R2 | CI873K01-eA | CI873K01-eA Ethernet/IP Communication Interface |
| 3BSC690164R1 | LD 800DN | LD 800DN EtherNet/IP to DeviceNet Linking Device, G1 compliant |
| 3BSE066485R2 | PM851AK01-eA | PM851AK01-eA Processor Unit |
| 3BSE066490R2 | PM856AK01-eA | PM856AK01-eA Processor Unit |
| 3BSE066495R2 | PM860AK01-eA | PM860AK01-eA Processor Unit |
| 3BSE018157R2 | PM861AK01-eA | PM861AK01-eA Processor Unit |
| 3BSE018160R2 | PM861AK02-eA | PM861AK02-eA Redundant Processor Unit |
| 3BSE018161R2 | PM864AK01-eA | PM864AK01-eA Processor Unit |
| 3BSE018164R2 | PM864AK02-eA | PM864AK02-eA Redundant Processor Unit |
| 3BSE050198R2 | PM866K01-eA | PM866K01-eA Processor Unit |
| 3BSE050199R2 | PM866K02-eA | PM866K02-eA Redundant Processor Units |
| 3BSE053241R2 | PM891K01-eA | PM891K01-eA Processor Unit |
| 3BSE053242R2 | PM891K02-eA | PM891K02-eA Redundant Processor Unit |
| 3BSE018172R1 | SB822 | SB822 Rechargeable battery unit External DIN-rail mounted rechargeable battery unit including lithium-ion battery, 24V DC connector and connection cable TK821V020 Width=85 mm Equivalent amount of Lithium metal=0,8g (0,03oz) |
| 3BSC610054R1-M | SD822Z | SD822Z Power Supply Device |
| 3BSC610055R1-M | SS822Z | SS822Z Power Voting Unit |
| 3BSC950193R1 | TB850 | TB850 CEX-Bus Terminator With 25-pin DB25P male connector. With screw fixing. A TB850 CEX-Bus terminator must always be installed on the last unit on the CEX bus. |
| 3BSC950194R1 | TB851 | TB851 CEX-Bus Terminator With 25-pin DB25S female connector. With screw fixing. When Communication Interface units are mounted on adjacent DIN rails, they are connected by means of a CEX-Bus extension cable (TK850) and terminated using a TB851 CE |
| 3BSC950263R1 | TB852 | TB852 RCU Link Terminator |
| 3BSE057022R1 | TB853 | TB853 RCU Control Link Terminator |
| 3BSC630049R1 | TC562 | TC562 Short Distance Modem length < 10 km. Point-to-point up to 1 km at 19200 bps. Power 24V d.c Width=55 mm |
| 3BSC630197R1-M | TK212A | TK212 Tool cable RJ45 to Dsub-9 (female), length 3 m For connection of FS801 and CI840 to PC |
| 3BSC950192R1 | TK850V007 | TK850V007 CEX-Bus Extension Cable Length= 0.7 m Use of TK850V007 needs TK851 as CEX-bus terminator. |
| 3BSC950262R1 | TK851V010 | TK851V010 Connection Cable Length= 1.0 m Used as: - RCU Link Cable - BC810 Interconnection Cable |
| 3BSC950201R1 | TK853V020 | TK853V020 Modem Cable Length 2 m Cable for connection between modem TC562 and TP830 |
| 3BSC950356R1 | TK855 | TK855 RCU Data Link Cable |
| 3BSE057021R1 | TK856 | TK856 RCU Control Link Cable |
| 3BSC950375R1 | TK857V003 | TK857V003 RCU Link Cable |
Compact HMI | ||
| 3BSE064066R2500 | 2500 Signals | 2500 Signals |
| 3BSE064066R50 | 50 Signals | 50 Signals |
| 3BSE064066R500 | 500 Signals | 500 Signals |
| 3BSE064069R1 | Alarm Management | Alarm Management |
| 3BSE061477R510 | Compact HMI 800 5.1 DVD media only, latest revision | Compact HMI 800 5.1 DVD media only, latest revision |
| 3BSE040587-510 | Compact HMI 800 5.1 Getting Started | Compact HMI 800 5.1 Getting Started |
| 3BSE064644R1 | Dongle for USB Port | Dongle for USB Port |
| 3BSE064068R1000 | HMI Operator Workplace Client - 1000 Signals | HMI Operator Workplace Client - 1000 Signals |
| 3BSE064068R5001 | HMI Operator Workplace Client - 10000 Signals | HMI Operator Workplace Client - 10000 Signals |
| 3BSE064068R200 | HMI Operator Workplace Client - 200 Signals | HMI Operator Workplace Client - 200 Signals |
| 3BSE064068R2000 | HMI Operator Workplace Client - 2000 Signals | HMI Operator Workplace Client - 2000 Signals |
| 3BSE064068R500 | HMI Operator Workplace Client - 500 Signals | HMI Operator Workplace Client - 500 Signals |
| 3BSE064068R5000 | HMI Operator Workplace Client - 5000 Signals | HMI Operator Workplace Client - 5000 Signals |
| 3BSE064070R1000 | HMI Operator Workplace Remote Client - 1000 Signals | HMI Operator Workplace Remote Client - 1000 Signals |
| 3BSE064070R5001 | HMI Operator Workplace Remote Client - 10000 Signals | HMI Operator Workplace Remote Client - 10000 Signals |
| 3BSE064070R200 | HMI Operator Workplace Remote Client - 200 Signals | HMI Operator Workplace Remote Client - 200 Signals |
| 3BSE064070R2000 | HMI Operator Workplace Remote Client - 2000 Signals | HMI Operator Workplace Remote Client - 2000 Signals |
| 3BSE064070R500 | HMI Operator Workplace Remote Client - 500 Signals | HMI Operator Workplace Remote Client - 500 Signals |
| 3BSE064070R5000 | HMI Operator Workplace Remote Client - 5000 Signals | HMI Operator Workplace Remote Client - 5000 Signals |
| 3BSE079194R10 | HMI Smart Client Workplace - Client 1-10 | HMI Smart Client Workplace - Client 1-10 |
| 3BSE034585R1 | RAINBOW SuperPro Dongle for Parallel Port | RAINBOW SuperPro Dongle for Parallel Port |
| 3BSE062160R510 | Server | HMI Operator and Engineering Workplace - Server |
S800IO | ||
| 3BSE020512R2 | AI801-eA | AI801-eA Analog input 1x8 ch, |
| 3BSE008516R2 | AI810-eA | AI810-eA Analog input 1x8 ch. |
| 3BSE052604R2 | AI815-eA | AI815-eA Analog Input 1x8 ch with HART |
| 3BSE008544R2 | AI820-eA | AI820-eA Analog input 4x1 ch. |
| 3BSE036456R2 | AI825-eA | AI825-eA Analog Input 4x1ch Galv. isol. |
| 3BSE040662R2 | AI830A-eA | AI830A-eA Analog input 1x8ch RTD |
| 3BSE051306R2 | AI835A-eA | AI835A-eA Analog input 8 ch. Thermocouple/mV |
| 3BSE028925R2 | AI843-eA | AI843-eA Analog Input , Redundant or Single 1x8chTermocouple/mV |
| 3BSE023675R2 | AI845-eA | AI845-eA Analog Input. Redundant or single 1x8ch. HART. |
| 3BSC690071R1 | AI890 | AI890 Analog Input 1x8 ch with Intrinsic Safety Interface 0 (4)...20mA single ended 0,1%. Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSC690141R1 | AI893 | AI893 Analog Input 8 ch. Temp. measuring. Intrinsic Safety Interf. G3 compliant. For TC and RTD sensors. Rated isol. 50V. Use Module Termination Unit TU890 or TU891. |
| 3BSC690086R1 | AI895 | AI895 Analog Input 1x8 ch with Intrinsic Safety and HART Int |
| 3BSE020514R2 | AO801-eA | AO801-eA Analog output 1x8 ch, |
| 3BSE038415R2 | AO810V2-eA | AO810V2-eA Analog Output 1*8 channels, 0(4)...20mA |
| 3BSE052605R2 | AO815-eA | AO815-eA Analog Output 1x8 ch with HART |
| 3BSE008546R2 | AO820-eA | AO820-eA Analog Output 4x1 ch, |
| 3BSE045584R2 | AO845A-eA | AO845A-eA Analog Output Redundant or single 1x8ch HART |
| 3BSC690072R1 | AO890 | AO890 Analog Output 1x8 ch with Intrinsic Safety Interface 0 (4)...20mA 0,1%. RL max 750 ohm Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSC690087R1 | AO895 | AO895 Analog Output 1x8 ch with Intrinsic Safety and HART Interf. G3 compliant. 4...20mA 0,1%. RL max 750 ohm Rated isol. 50V. Use Module Termination Unit TU890 or TU891. |
| 3BSE022366R2 | CI801-eA | CI801-eA PROFIBUS DP-V1 Communication Interface |
| 3BSE038540R1300 | CI801KIT | CI801 Engineering kit Including: 1 pce Diskette with GSD file and Release Note. 1 pce Reference Manual Memory Maps for CI801. |
| 3BSE041882R2 | CI840A-eA | CI840A-eA Profibus DP-V1 Communication Interface.For 1+1 redundant operation. |
| 3BSE031694R4000 | CI840KIT | CI840 Engineering Kit Including: 1 pce Diskette with GSD file and Release Note. 1 pce Reference Manual Memory Maps for CI840 |
| 3BSE020508R2 | DI801-eA | DI801-eA Digital Input 24V d.c. |
| 3BSE022360R2 | DI802-eA | DI802-eA Digital Input 120V a.c./d.c., 8x1ch. |
| 3BSE022362R2 | DI803-eA | DI803-eA Digital Input 230V a.c./d.c., 8x1ch. |
| 3BSE008508R2 | DI810-eA | DI810-eA Digital Input 24V d.c. 2x8 ch. |
| 3BSE008552R2 | DI811-eA | DI811-eA 2x8 ch 48V Digital input |
| 3BUR001454R2 | DI814-eA | DI814-eA Digital Input 24V d.c. Current Source 2x8 ch, |
| 3BSE069052R2 | DI818-eA | DI818-eA Digital Input 24V d.c. 32 ch |
| 3BSE008512R2 | DI820-eA | DI820-eA Digital Input 120V a.c./d.c. |
| 3BSE008550R2 | DI821-eA | DI821-eA Digital Input 230V a.c./d.c. |
| 3BSE036373R2 | DI825-eA | DI825-eA Digital Input 1x8ch , 125V d.c. SOE |
| 3BSE069054R2 | DI828-eA | DI828-eA Digital Input, 120V a.c./d.c. 16 ch |
| 3BSE013210R2 | DI830-eA | DI830-eA Digital Input 24V d.c. SOE |
| 3BSE013212R2 | DI831-eA | DI831-eA Digital Input 48V d.c.,SOE |
| 3BSE020836R2 | DI840-eA | DI840-eA Digital Input. Redundant or single, 24V d.c., 1x16ch |
| 3BSE013088R1 | DI885 | DI885 Digital Input 24/48V d.c.,SOE 1x8 ch, Rated isol. 50V Use Module Termination Unit TU810, TU812, TU814, TU830. |
| 3BSC690073R1 | DI890 | DI890 Digital Input 8x1 ch with Intrinsic Safety Interface Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSE020510R2 | DO801-eA | DO801-eA Digital Output 16ch. 24V d.c. 0.5A. |
| 3BSE022364R2 | DO802-eA | DO802-eA Digital Output, Relay. Normal open |
| 3BSE008510R2 | DO810-eA | DO810-eA Digital Output 24 V d.c. |
| 3BUR001455R2 | DO814-eA | DO814-eA Digital Output current sinking |
| 3BSE013258R2 | DO815-eA | DO815-eA Digital Output 24V d.c |
| 3BSE069053R2 | DO818-eA | DO818-eA Digital Output 24V d.c. 32 ch |
| 3BSE008514R2 | DO820-eA | DO820-eA Digital Output, Relay. Normal open |
| 3BSE013250R2 | DO821-eA | DO821-eA Digital Output, Relay. Normal closed |
| 3BSE069055R2 | DO828-eA | DO828-eA Digital Output, Relay Normally Open, 16 ch |
| 3BSE020838R2 | DO840-eA | DO840-eA Digital Output. Redundant or single. |
| 3BSC690074R1 | DO890 | DO890 Digital Output 4x1 ch with Intrinsic Safety Interface Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSE013228R2 | DP820-eA | DP820-eA Pulse Counter RS-422, Current, 5V, (12V), 24V |
| 3BSE028926R2 | DP840-eA | DP840-eA Pulse Counter or Frequency Measurement Module. Redundant or single. |
| 3BSE038407R1 | FS801K01 | FS801K01 firmware upgrade tool |
| 3BSC610054R1 | SD822Z | SD822Z Power Supply Device |
| 3BSC610064R1 | SD831 | SD831 Power Supply Device |
| 3BSC610065R1 | SD832 | SD832 Power Supply Device |
| 3BSC610066R1 | SD833 | SD833 Power Supply Device |
| 3BSC610067R1 | SD834 | SD834 Power Supply Device |
| 3BSC610055R1 | SS822Z | SS822Z Power Voting Unit |
| 3BSC610068R1 | SS832 | SS832 Voting Device |
| 3BSE008534R1 | TB805 | TB805 Bus Outlet Modulebus extension cable adaptor D-sub 25, female One requried per extension cable TK801 |
| 3BSE008536R1 | TB806 | TB806 Bus Inlet Modulebus extension cable adaptor D-sub 25, male One requried per extension cable TK801 |
| 3BSE008538R1 | TB807 | TB807 Modulebus terminator |
| 3BSE013208R2 | TB820V2-eA | TB820V2-eA Modulebus Cluster Modem |
| 3BSE036634R2 | TB825-eA | TB825-eA Optical Media Converter Multi Mode |
| 3BSE061637R2 | TB826-eA | TB826-eA Optical Media Converter Single Mode |
| 3BSE037760R2 | TB840A-eA | TB840A-eA Modulebus Cluster Modem |
| 3BSE022464R1 | TB842 | TB842, Modulebus Optical Port Used together with CI801 and CI840, connected via TB806 or TB846. 10 Mbits driver. |
| 3BSE021437R1 | TB845 | TB845, Dual Modulebus outlet Modulebus extension cable adaptor two D-sub, female. Two TK801 cables for redundancy |
| 3BSE021439R1 | TB846 | TB846, Dual Modulebus inlet Modulebus extension cable adaptor two D-sub, male. Two TK801 cables for redundancy |
| 3BSC630197R1 | TK212A | TK212 Tool cable RJ45 to Dsub-9 (female), length 3 m For connection of FS801 and CI840 to PC |
| 3BSC950089R1 | TK801V003 | TK801V003 Cable. Modulebus Extension Shielded Cable 0.3m D-sub 25, male-female.G3 compliant |
| 3BSC950089R2 | TK801V006 | TK801V006 Cable. Modulebus Extension Shielded Cable 0.6m D-sub 25, male-female. G3 compliant |
| 3BSC950089R3 | TK801V012 | TK801V012 Cable. Modulebus Extension Shielded Cable 1.2m D-sub 25, male-female. G3 compliant. |
| 3BSC950107R1 | TK811V015 | TK811V015 POF Cable, 1.5m, Duplex L=1.5m latching duplex connector Duplex plastic fibre |
| 3BSC950107R2 | TK811V050 | TK811V050 POF Cable, 5m, Duplex L=5m latching duplex connector Duplex plastic fibre |
| 3BSC950107R3 | TK811V150 | TK811V150 POF Cable, 15m, Duplex L=15m latching duplex connector Duplex plastic fibre |
| 3BSC950118R1 | TK812V015 | TK812V015 POF Cable, 1.5m, Simplex L=1.5m latching connector Simplex plastic fibre |
| 3BSC950118R2 | TK812V050 | TK812V050 POF Cable, 5m, Simplex L=5.0m latching connector Simplex plastic fibre |
| 3BSC950118R3 | TK812V150 | TK812V150 POF Cable, 15m, Simplex L=15m latching connector Simplex plastic fibre |
| 3BSE035990R1 | TU805K01 | TU805K01 Termination Units for two or three wire connection of DI801 and DO801 Include 10 pcs of Termination Unit TU805 |
| 3BSE039025R1 | TU807 | TU807, Termination Unit for TB840/TB840A |
| 3BSE013230R1 | TU810V1 | TU810V1 Compact Module Termination Unit, MTU, 50V. 2x8 signal terminals, rated isol. 50V. |
| 3BSE013231R1 | TU811V1 | TU811V1 Compact Module Termination Unit, MTU, 250V. 1x8 signal terminals, rated isol. 250V. |
| 3BSE013232R1 | TU812V1 | TU812V1 Compact Module Termination Unit, MTU, 50V. With 25 pin D-sub connector, rated isol. 50V. D-sub (female) connector is not enclosed. |
| 3BSE036714R1 | TU813 | TU813 Compact Module Termination Unit, MTU, 250V 2x8 Signal terminals, Rated isol. 250V Detachable (pluggable) connectors are not enclosed. |
| 3BSE013233R1 | TU814V1 | TU814V1 Compact Module Termination Unit, MTU, 50V. 2x8 Signal terminals, rated isol. 50V. Detachable (pluggable) connectors are not enclosed. |
| 3BSE069209R1 | TU818 | TU818 Compact Module Termination Unit, MTU, 50V 1x32 (and 2x16) signal terminals, Rated isol. 50V |
| 3BSE068891R1 | TU819 | TU819 Compact Module Termination Unit, MTU, 50V. With 2x25 pin D-sub connector, Rated isol. 50V, D-sub (female) connector is not enclosed |
| 3BSE013234R1 | TU830V1 | TU830V1 Extended Module Termination Unit, MTU, 50V. 2x16 signal terminals, rated isol. 50V. |
| 3BSE013235R1 | TU831V1 | TU831V1 Extended Module Termination Unit, MTU, 250V. 2x8 signal terminals, rated isol. 250V. |
| 3BSE038726R1 | TU833 | TU833 Extended Module Termination Unit, MTU, 50V. 2x16 signal terminals, Rated isol. 50V. Spring-cage terminals. |
| 3BSE013236R1 | TU835V1 | TU835V1 Extended Module Termination Unit, MTU, 50V. 8 fused power outlets, 8 signal terminals, rated isol. 50V. |
| 3BSE013237R1 | TU836V1 | TU836V1 Extended Module Termination Unit, MTU, 250V. 2x4 fused signals, 2x4 return terminals, 2x2 L 2x2N terminals, rated isol. 250V. |
| 3BSE013238R1 | TU837V1 | TU837V1 Extended Module Termination Unit, MTU, 250V. 8x1 fused isol. signals, 8x1 L terminals, 2x6 N terminals, rated isol. 250V. |
| 3BSE008572R1 | TU838 | TU838 Extended Module Termination Unit, MTU, 50V. 2x4 fused transducer power outlets, 16 signal terminals, 2x4 return terminals, 2x2 L+, 2x2 L- terminals, rated isol. 50V. Module is mounted horizontally. |
| 3BSE046966R1 | TU839 | TU839 Extended Module Termination Unit, 250V 2x8 signal terminals 2x4 fused sensor power Rated isol. 250V |
| 3BSE020846R1 | TU840 | TU840, Termination Unit for 1+1 TB840 Support for redundant I/O Including: 1 pce Power Supply Connector 2 pce TB807 Modulebus Terminator |
| 3BSE020848R1 | TU841 | TU841, Termination unit for 1+1 TB840 Support for non-redund |
| 3BSE020850R1 | TU842 | TU842 MTU, for redundant AO/DI/DO84X, Horizontal mounted |
| 3BSE021443R1 | TU843 | TU843 MTU, for redundant AO/DI/DO84X, Vertical mounted |
| 3BSE021445R1 | TU844 | TU844 MTU, for redundant AI845, Horizontal mounted |
| 3BSE021447R1 | TU845 | MTU, for redundant AI845, Vertical mounted |
| 3BSE022460R1 | TU846 | TU846, Mounting unit for 1+1 TU847,redundant I/O |
| 3BSE022462R1 | TU847 | TU847, Mounting unit for 1+1 TU847,non-redundant I/O |
| 3BSE042558R1 | TU848 | TU848, MTU with individual power supply for red. TB840/TB840A. Support for dual modulebus. Including: 2 pcs TB807 |
| 3BSE042560R1 | TU849 | TU849, MTU with individual power supply for red. TB840/TB840A. Support for single modulebus Including: 1 pcs TB807 |
| 3BSE050930R1 | TU850 | TU850 Extended Module Termination Unit, MTU, 50V 2x8 signal terminals and 2x8 disconnetable current limited sensor/transmitter outlet power terminals. Rated isol. 50V. |
| 3BSE068782R1 | TU851 | TU851 Extended Module Termination Unit, MTU, 250V 2x16 signal terminals, Rated isol. 250V |
| 3BSE069964R1 | TU852 | TU852 Module Termination Unit, MTU, for redundant applications, 50V Horizontal mounted DIN rail, used with redundnat AO, DI, DO and DP I/O modules, with 2x25 pin D-sub connector, Rated isol. 50V |
| 3BSE069966R1 | TU854 | TU854 Module Termination Unit, MTU, for redundant applications, 50V Horizontal mounted DIN rail, used with redundnat AI and DP I/O modules, with 1x25 pin D-sub connector, Rated isol. 50V, Shunt Stick not included |
| 3BSC690075R1 | TU890 | TU890 Module Termination Unit for Intrinsic Safety applications 3x9 signal terminals Rated isol. 50V. Including wiring separator. |
| 3BSC840157R1 | TU891 | TU891 Module Termination Unit for non Intrinsic Safety applications 3x9 signal terminals Rated isol. 50V. |
| 3BSE023607R1 | TY801K01 | TY801K01 8pcs Shunt Stick TY801 125 + 125 ohms shunt. Used for AI845 and AI880 on TU844, TU845 |
| 3BSE033670R1 | TY804K01 | TY804K01 8pcs Shunt Stick TY804 1000 ohms shunt. Used for DP840 on TU844, TU845 |
| 3BSE056980R1 | TY820K01 | TY820K01 10pcs Temperature Sensor TY820 |
Freelance Controller | ||
| 3BDH000050R1 | AM811F | Battery Module, w/o battery |
| 3BDH000044R1 | AM895F(4) | AM 895F Front panel 4pcs |
| 3BDH000395R0005 | CI 773F | CI 773F, Communication Interface, PROFIBUS DP Master |
| 3BDH001010R0001 | CI 930F | CI 930F, Communication Interface, PROFIBUS DP Master DP-V0/V1, 12 MBit/s Supports PROFIBUS line redundancy (TU 951F required) D-Sub, 9-pole for Line A Software version 2013 or higher is mandatory. Requires one coupler bus slot on the CPU module. L |
| 3BDH001010R0005 | CI 930F(eA) | CI 930F, Communication Interface, PROFIBUS DP Master |
| 3BDH000368R0001 | CM772F | PROFIBUS DP Master Modul |
| 3BDH000022R1 | EI813F | 10BASET- (Twisted Pair), w/o battery |
| 3BDH000030R1 | FI810F | CAN-3 (triple channel for Freelance I/O) |
| 3BDH000031R1 | FI820F | Serial (dual channel) |
| 3BDH000032R1 | FI830F | Profibus-DP V1 |
| 3BDH000033R1 | FI840F | Foundation Fieldbus |
| 3BDH001001R0005 | PM 901F | PM 901F, Central Processing Unit (Lite) 3 Ethernet interfaces, 3 MB battery buffered memory, 400 MHz CPU clock, processing of max. 400 IO鈥檚. 2 slots for assembling Communication Interface Module Without operating system. The operating system has to be loaded during software installation. Needs external 24 VDC power supply. Software version 2015 or higher is mandatory. Gray housing. Display Unit TD 951F and Battery TA 951F are not included. UL Class 1 Div 2 certification is in preparation. |
| 3BDH001000R0001 | PM 902F | PM 902F, Central Processing Unit (Standard) 2 slots for assembling Communication Interface Modules Without operating system. The operating system has to be loaded during software installation. Needs external 24 VDC power supply Software version 20 |
| 3BDH001000R0005 | PM 902F(eA) | PM 902F, Central Processing Unit (Standard) |
| 3BDH000364R0002 | PM783F | Controller CPU module (2MB), without base |
| 3BDH000530R1 | PM803F | Base unit, 16 MByte |
| 3BDM000190R1 | RW 856F | RW 856F, Mounting Accessory, for enforced wall mounting |
| 3BDM000169R1 | RY885F | RY 885F, Grounding Strap, 2 pcs. |
| 3BDH000013R1 | SA811F | Powersupply module 115/230V ->24VDC |
| 3BDM000199R1 | SB808F | Battery for DFE, EI80xF for RAM buffering |
| 3BDH000014R1 | SD812F | Power supply 24 V DC，To use together with PM 802F or PM 803F.Software V7.1SP2a or higher is mandatory. |
| 3BDH000042R1 | SY809F | SY 809F Battery holder Without battery |
| 3BDH001031R0005 | TA 924F | TA 924F, Dummy Coupler Module |
| 3BDH001030R0001 | TA 951F | TA 951F, Battery for RAM buffering 2/3A Size, Lithium |
| 1SAP180300R0001 | TA521 | Lithium battery for RAM cache |
| 1SAP180700R0001-F | TA525 | TA525, White Labels, 10 pcs. |
| 1SAP180800R0001-F | TA526 | Wall mounting bracket, (10 pieces/package) |
| 3BDH000367R0001 | TA724F | TA724F |
| 3BDH000365R0001 | TB711F | CPU terminal base |
| 3BDM000160R1 | TB870F | Terminal block to connect DFM02>DFA021, DFM03>DFA031 |
| 3BDH001020R0001 | TD 951F | TD 951F, Display Unit 64 x 128 Dot Matrix LCD |
| 3BDH001020R0005 | TD 951F(eA) | TD 951F, Display Unit |
| 3BDH000366R0001 | TK701F | Serial diagnostic cable, 5m, Sub-D/Sub-D |
| 3BDM000213R1 | TK802F | TK 802F, 24 V DC, with wire end ferrules length 2 m. For SD 802F/ SD 812F |
| 3BDM000210R1 | TK807F | TK 807F, 115/230 V AC, with wire end ferrules length 2 m. For SA 801F/ SA 811F |
| 3BDM000211R1 | TK808F | 115/230 V AC, with Euro plug length 2 m. For SA 801F/ SA 811F |
| 3BDM000212R1 | TK809F | 115/230 V AC, with US plug length 2 m. For SA 801F/ SA 811F |
| 3BDM000103R1 | TK811F | TK 811F, CAN cable, length 3 m. 3x2x0,25mm ar Open end with wire end ferrules. Identical with DFA 011. |
| 3BDM000150R1 | TK821F | TK 821F, Cable serial (dual channel), with integral connectors length 0.5 m. Identical with DFA 021. |
| 3BDM000100R1 | TK831F | CAN (triple channel), 0.5m with connectors for DFM03/ DFA 070 |
| 3BDM000202R1 | TK890F | Diagnostics cable, length 10 m. Identical with DSU 141 |
| 3BDM000201R1 | TK891F | Diagnostics cable, length 5 m. Identical with DSU 141 |
| 3BDH001035R0001 | TU 951F | TU 951F, PROFIBUS Terminal for Line B D-Sub, 9-pole for line B Connection cable included Delivery time and quantity on request. Please contact the Singapore delivery center. |
| 3BDM000172R1 | TV 822F | TV 822F, Clip for shielding, 16 mm, 5 pcs. |
| 3BDM000173R1 | TV 823F | TV 823F, Clip for shielding, 16...25 mm, 5 pcs. |
| 3BDM000174R1 | TV 824F | TV 824F, Clip for shielding, 23...35 mm, 5 pcs. |
| 3BDM000175R1 | TV 825F | TV 825F, Clip for shielding, 25...40 mm, 5 pcs. |
| 3BDM000180R1 | TV 831F | TV 831F, Clamp-type terminal, 3...10 mm, 5 pcs. |
| 3BDM000181R1 | TV 832F | TV 832F, Clamp-type Terminal, 16?0 mm, 5 pcs. |
Freelance | ||
| 2PAA110438R08 | Batch for Extended Automation | Batch for Extended Automation Interface to 800xA Batch Please refer to Extended Automation 800xA price list for the batch application (license). |
| 3BDS008520R08 | CBF P | Control Builder F Professional CBF Professional supports - All features of Control Builder F Standard - Security Lock - User Defined Function Blocks (developer license) - OPC Function Block Classes (developer license) - FDT Technology - DTM |
| 3BDS008510R08 | CBF S | Control Builder F Standard CBF Standard supports - 16 Character Tag Names - User Defined Function Blocks (runtime license) - OPC Function Block Classes (runtime license) Included in this license - WEB Display Configuration Order one Control Build |
| 3BDS008502R0821 | Chinese language | Chinese language |
| 3BDS008794R08 | Combined Workplace | Combined Workplace Expands an engineering workplace to a combined workplace (Control Builder + DigiVis). Only in combination with Control Builder F licenses. Order one Combi hardkey for each combined workplace. |
| 3BDS009973R08 | Control Aspect | Control Aspect Display (read only) of Control Builder F function block diagrams in DigiVis. |
| 3BDS008790R08 | DigiVis | DigiVis DigiVis supports - Control of all Tags - Graphical Displays, Trends, Faceplates - Historian, Reports, Operator Logs - SFC Display, Time Scheduler Included in this license - Extended Diagnostic - WEB display (runtime license) - DigiBrow |
| 3BDS008784R08 | Dual Monitor Support | Dual Monitor Support For a single operator workplace |
| 3BDS008502R0801 | English language | Chinese language |
| 2PAA110437R08 | Freelance Batch | Freelance Batch Interface to Workflow Manager (BCM module) Please refer to Decathlon Suite WFM price list for the batch application (license). |
| 2PAA110436R08 | Freelance Formulation | Freelance Formulation Essential Recipe Manager This license includes a license for the Freelance Formulation batch application. |
| 3BDS008531R0821 | Freelance Software 2013, Chinese and English CD ROM | Freelance Software 2013, Chinese and English CD ROM |
| 2PAA110434R08 | Generic OPC | OPC Server (Windows 7, Windows 2008) |
| 2PAA110432R08 | Number of supported controllers incl. 50 IOs each | Number of supported controllers incl. 50 IOs each |
| 2PAA110435R08 | OPC for Extended Automation | OPC for Extended Automation OPC Server (Windows 7, Windows 2008) Connection to 800xA Operation and Process Portal B |
| 2PAA110433R08 | Set of 50 I/Os | Set of 50 I/Os |
| 3BDS008758R08 | TeleControl | TeleControl Support for IEC 60870-5-101 and -104 Check whether the implemented subset of functionality meets your requirements. IEC 60870-5-104 is currently not released with DCP 02/10 and DFC 01/02. |
| 3BDS008755R08 | Trend Server Package | Trend Server Package For trending data on DigiVis without using trend acquisition function block. Only one Trend Server is possible per system. |
Freelance 2016 | ||
| 2PAA110438R09 | Batch for Extended Automation | Batch for Extended Automation Interface to 800xA Batch Please refer to Extended Automation 800xA price list for the batch application (license). |
| 3BDS008794R09 | Combined Workplace | Combined Workplace Extends an Engineering workplace to a combined workplace. Freelance Operations (Standard) and Freelance Engineering can be used on the same workplace. Only in combination with an Engineering licenses. Order one Combi hardkey for each combined workplace. |
| 3BDS009973R09 | Control Aspect | Control Aspect Display (read only) of function block diagrams on an Freelance operator workplace. |
| 3BDS008784R09 | Dual Monitor Support | Dual Monitor Support For a single operator workplace |
| 3BDS008520R09 | Engineering (Professional) | Engineering (Standard) - Security Lock - User Defined Function Blocks (developer license) - OPC Function Block Classes (developer license) - FDT Technology - DTM Device Driver Please check the list of DTMs which are approved by ABB for use with Freelance Engineering in version 2015. Order one Engineering hardkey for each engineering workplace |
| 3BDS008510R09 | Engineering (Standard) | Engineering (Standard) Freelance Engineering (Standard) supports - 16 Character Tag Names - User Defined Function Blocks (runtime license) - OPC Function Block Classes (runtime license) Included in this license - WEB Display Configuration Order one Engineering hardkey for each engineering workplace |
| 3BDS008502R0901 | English language | English language |
| 3BDS008536R0903 | Freelance 2016 Product Box, German and English | Freelance 2016 Product Box, German and English |
| 2PAA110437R09 | Freelance Batch | Freelance Batch Interface to Freelance Batch |
| 2PAA110436R09 | Freelance Formulation 1.1 | Freelance Formulation 1.1 Essential Recipe Manager German and English user interfaces |
| 3BDS008531R0903 | Freelance Software 2016, German and English CD ROM | Freelance Software 2016, German and English CD ROM |
| 2PAA110434R09 | Generic OPC | Generic OPC OPC Server (Windows 7, Windows 2008) |
| 2PAA110432R09 | Number of supported controllers incl. 50 IOs each | Number of supported controllers incl. 50 IOs each |
| 2PAA110435R09 | OPC for Extended Automation | OPC for Extended Automation OPC Server (Windows 7, Windows 2008) Connection to 800xA Operation and Process Portal B |
| 2PAA114214R09 | Operations (Lite) | Operations (Lite) Freelance Operations (Lite) supports - All features of Freelance Operations (Standard) - Limited number user defined graphic displays (max. 5 FGR) - No license options available No server required. Order one Operations hardkey for each operator workplace. |
| 3BDS008790R09 | Operations (Standard) | Freelance Operations (Standard) supports - Control of all Tags - Graphical Displays, Trends, Faceplates - Historian, Reports, Operator Logs - SFC Display, Time Scheduler Included in this license - Extended Diagnostic - WEB display (runtime license) - Archive Browser No server required. Order one Operations hardkey for each operator workplace. |
| 2PAA110433R09 | Set of 50 I/Os | Set of 50 I/Os |
| 3BDS008758R09 | TeleControl | TeleControl Support for IEC 60870-5-101 and -104 Check whether the implemented subset of functionality meets your requirements. IEC 60870-5-104 is currently not released with DCP 02/10 and DFC 01/02. |
| 3BDS008755R09 | Trend Server Package | Trend Server Package For trending data on Freelance Operations without using trend acquisition function block. Only one Trend Server is possible per system. |
Profibus & Networks | ||
| 3BDZ000370R1 | PCO 010 | PCO 010, PROFIBUS DP connector, standard |
| 3BDZ000371R1 | PCO 011 | PROFIBUS DP connector with bus termination |
| 3BDZ000372R1 | PCO 012 | PCO 012, PROFIBUS DP connector with bus termination and adapter |
| 3BDZ000398R1 | RLM01 | PROFIBUS Redundancy Link Module for PROFIBUS line redundancy |
S700IO | ||
| 3BDH000369R0001 | AC722F | AC 722F, Analog Input/Output Module 8 AI/AO: +-10 V, 0/4-20 mA, RTD 12 Bit + sign, 2-wire, 24 VDC 5 W TU 715F /TU 716F (terminal unit not included) |
| 3BDH000376R0001 | AI723F | AI 723F, Analog Input Module 16 AI: +-10 V, 0/4-20 mA 24 VDC, Pt100 12 Bit + sign, 2-wire, 24 VDC 5 W TU 715 F /TU 716F ( terminal unit not included) |
| 3BDH000385R0001 | AI731F | 8-point 15 bit analog input module, without base |
| 3BDH000384R0001 | AO723F | 16 point analog output module without base |
| 3BDH000370R0001 | AX721F | AX 721F, Analog Input/Output Module 4 AI: +-10 V, 0/4-20 mA, RTD, 24 VDC 4 AO: +-10 V, 0/4-20 mA 12 Bit + sign, 2-wire, 24 VDC 5 W TU 715F /TU 716F (terminal unit not included) |
| 3BDH000377R0001 | AX722F | AX 722F, Analog Input/ Output Module 8 AI: +-10 V 0/4-20 mA 24 VDC, Pt100 8 AO: +-10 V 0/4-20 mA 24 VDC 12 Bit + Sign, 2-wire, 24 VDC 5W Without terminal unit. |
| 3BDH000393R0001 | CD 722F | CD 722F, Frequency Input Module 2 Counter Inputs: 5/24 VDC, 1 Vpp sinus, fmax 300 kHz 2 DO: 24 VDC/0,1 A, pulse width PWM 2 DI: 24 VDC 8 DI/DO: 24 VDC/0,5 A 1/2-wire, 24 VDC 100 W TU 715F /TU 716F (terminal unit not included) |
| 3BDH001041R0001 | CP-C 24/10.0 | Power Supply, 10A@24 VDC |
| 3BDH001040R0001 | CP-C 24/5.0 | Power Supply, 5A@24 VDC output |
| 3BDH000371R0001 | DA701F | DA 701F, Digital/Analog Module 16 DI: 24 VDC 8 DI/DO: 24 VDC/0.5 A 4 AI: +-10 V 0/4-20 mA, RTD , 24 VDC 2 AO: +-10 V, 0/4-20 mA 12 Bit + sign, 1-wire, 24 VDC 200 W TU 715F /TU 716F (terminal unit not included) |
| 3BDH000388R0001 | DC 705F | DC 705F, PROFIBUS Interface Module Interface for Fieldbus Plug FBP 8 DI: 24 VDC 8 DI/DO: 24 VDC/0.5 A 1-wire, 24 VDC 100 W TU 705F /TU 706F (terminal unit not included) |
| 3BDH000372R0001 | DC722F | DC 722F, Digital Input/Output Module 16 DI/DO: 24 VDC/0.5 A 2-wire, 24 VDC 200 W TU 715F /TU 716F (terminal unit not included) |
| 3BDH000373R0001 | DC723F | DC 723F, Digital Input/Output Module 24 DI/DO: 24 VDC/0.5 A 1-wire, 24 VDC 300 W TU 715F /TU 716F (terminal unit not included) |
| 3BDH000375R0001 | DC732F | DC 732F, Digital Input/ Output Module 16 DI, 16 DC, 24 VDC/0.5 A, 1-Wire, 24 VDC 200W Without terminal unit. |
| 3BDH000374R0001 | DI724F | DI 724F, Digital Input Module 32 DI: 24 VDC 1-wire, 24 VDC 1 W TU 715F /TU 716F (terminal unit not included) |
| 3BDH000387R0001 | DX 731F | 12 point digital input/output module 8DI 230VAC/4DO relay contact, 24VDC, 230VAC, without base |
| 3BDH000383R0001 | DX722F | 16 point digital input/output module. 8DI/8DO relay contact, 24VDC, 230VAC, without base |
| 1SAP180500R0001 | TA523 | TA523, Pluggable Marker Holder for I/O modules, 10 pcs. |
| 1SAP180700R0001 | TA525 | TA525, White Labels, 10 pcs. |
| 1SAP180800R0001 | TA526 | Wall mounting bracket, (10 pieces/package) |
| 3BDH000380R0001 | TU 731F | TU 731F, I/O Terminal Unit, 230 VAC Screw-type |
| 3BDH000381R0001 | TU 732F | TU 732F, I/O Terminal Unit, 230 VAC Spring-type |
| 3BDH000389R0001 | TU705F | TU 705F, FBP Terminal Unit, 24 VDC Screw-type |
| 3BDH000390R0001 | TU706F | TU 706F, FBP Terminal Unit, 24 VDC Spring-type |
| 3BDH000378R0001 | TU715F | TU 715F, I/O Terminal Unit, 24 VDC Screw-type |
| 3BDH000382R0001 | TU716F | TU 716F, I/O Terminal Unit, 24 VDC Spring-type |
S800IO | ||
| 3BSE020512R2-F | AI801-eA | AI801-eA Analog input 1x8 ch |
| 3BSE008516R2-F | AI810-eA | AI810-eA Analog input 1x8 ch. |
| 3BSE052604R2-F | AI815-eA | AI815-eA Analog Input 1x8 ch with HART |
| 3BSE008544R2-F | AI820-eA | AI820-eA Analog input 4x1 ch. |
| 3BSE036456R2-F | AI825-eA | AI825-eA Analog Input 4x1ch Galv. isol. |
| 3BSE040662R2-F | AI830A-eA | AI830A-eA Analog input 1x8ch RTD |
| 3BSE051306R2-F | AI835A-eA | AI835A-eA Analog input 8 ch. Thermocouple/mV |
| 3BSE028925R2-F | AI843-eA | AI843-eA Analog Input , Redundant or Single 1x8chTermocouple/mV |
| 3BSE023675R2-F | AI845-eA | AI845-eA Analog Input. Redundant or single 1x8ch. HART. |
| 3BSC690071R1-F | AI890 | AI890 Analog Input 1x8 ch with Intrinsic Safety Interface 0 (4)...20mA single ended 0,1%. Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSC690141R1-F | AI893 | AI893 Analog Input 8 ch. Temp. measuring. Intrinsic Safety Interf. G3 compliant. For TC and RTD sensors. Rated isol. 50V. Use Module Termination Unit TU890 or TU891. |
| 3BSC690086R1-F | AI895 | Analog Input 1x8 ch with Intrinsic Safety and HART Int |
| 3BSE020514R2-F | AO801-eA | AO801-eA Analog output 1x8 ch |
| 3BSE038415R2-F | AO810V2-eA | AO810V2-eA Analog Output 1*8 channels, 0(4)...20mA |
| 3BSE052605R2-F | AO815-eA | AO815-eA Analog Output 1x8 ch with HART |
| 3BSE008546R2-F | AO820-eA | AO820-eA Analog Output 4x1 ch |
| 3BSE045584R2-F | AO845A-eA | AO845A-eA Analog Output Redundant or single 1x8ch HART |
| 3BSC690072R1-F | AO890 | AO890 Analog Output 1x8 ch with Intrinsic Safety Interface 0 (4)...20mA 0,1%. RL max 750 ohm Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSC690087R1-F | AO895 | AO895 Analog Output 1x8 ch with Intrinsic Safety and HART Interf. G3 compliant. 4...20mA 0,1%. RL max 750 ohm Rated isol. 50V. Use Module Termination Unit TU890 or TU891. |
| 3BSE022366R2-F | CI801-eA | CI801-eA PROFIBUS DP-V1 Communication Interface |
| 3BSE038540R1300-F | CI801KIT | CI801 Engineering kit Including: 1 pce Diskette with GSD file and Release Note. 1 pce Reference Manual Memory Maps for CI801. |
| 3BSE041882R2-F | CI840A-eA | CI840A-eA Profibus DP-V1 Communication Interface.For 1+1 redundant operation. |
| 3BSE031694R4000-F | CI840KIT | CI840 Engineering Kit Including: 1 pce Diskette with GSD file and Release Note. 1 pce Reference Manual Memory Maps for CI840 |
| 3BSE020508R2-F | DI801-eA | DI801-eA Digital Input 24V d.c. |
| 3BSE022360R2-F | DI802-eA | DI802-eA Digital Input 120V a.c./d.c., 8x1ch. |
| 3BSE022362R2-F | DI803-eA | DI803-eA Digital Input 230V a.c./d.c., 8x1ch. |
| 3BSE008508R2-F | DI810-eA | DI810-eA Digital Input 24V d.c. 2x8 ch. |
| 3BSE008552R2-F | DI811-eA | DI811-eA 2x8 ch 48V Digital input |
| 3BUR001454R2-F | DI814-eA | DI814-eA Digital Input 24V d.c. Current Source 2x8 ch |
| 3BSE069052R2-F | DI818-eA | DI818-eA Digital Input 24V d.c. 32 ch |
| 3BSE008512R2-F | DI820-eA | DI820-eA Digital Input 120V a.c./d.c. |
| 3BSE008550R2-F | DI821-eA | DI821-eA Digital Input 230V a.c./d.c. |
| 3BSE069054R2-F | DI828-eA | DI828-eA Digital Input, 120V a.c./d.c. 16 ch |
| 3BSE020836R2-F | DI840-eA | DI840-eA Digital Input. Redundant or single, 24V d.c., 1x16ch. |
| 3BSC690073R1-F | DI890 | DI890 Digital Input 8x1 ch with Intrinsic Safety Interface Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSE020510R2-F | DO801-eA | DO801-eA Digital Output 16ch. 24V d.c. 0.5A. |
| 3BSE022364R2-F | DO802-eA | DO802-eA Digital Output, Relay. Normal open |
| 3BSE008510R2-F | DO810-eA | DO810-eA Digital Output 24 V d.c. |
| 3BUR001455R2-F | DO814-eA | DO814-eA Digital Output current sinking |
| 3BSE013258R2-F | DO815-eA | DO815-eA Digital Output 24V d.c |
| 3BSE069053R2-F | DO818-eA | DO818-eA Digital Output 24V d.c. 32 ch |
| 3BSE008514R2-F | DO820-eA | DO820-eA Digital Output, Relay. Normal open |
| 3BSE013250R2-F | DO821-eA | DO821-eA Digital Output, Relay. Normal closed |
| 3BSE069055R2-F | DO828-eA | DO828-eA Digital Output, Relay Normally Open, 16 ch |
| 3BSE020838R2-F | DO840-eA | DO840-eA Digital Output. Redundant or single. |
| 3BSC690074R1-F | DO890 | DO890 Digital Output 4x1 ch with Intrinsic Safety Interface Rated isol. 50V Use Module Termination Unit TU890 or TU891. |
| 3BSE013228R2-F | DP820-eA | DP820-eA Pulse Counter RS-422, Current, 5V, (12V), 24V |
| 3BSE028926R2-F | DP840-eA | DP840-eA Pulse Counter or Frequency Measurement Module. Redundant or single. |
| 3BSE038407R1-F | FS801K01 | FS801K01 firmware upgrade tool |
| 3BSC610054R1-F | SD822Z | SD822Z Power Supply Device |
| 3BSC610064R1-F | SD831 | SD831 Power Supply Device Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 3A. If redundant power application is required connect to SS8XX. Voting unit. Width=35mm. DIN rail mounted. |
| 3BSC610065R1-F | SD832 | SD832 Power Supply Device Input a.c. 100-120/200-240 V. Output d.c. 24 V 5A, auto-select input. If redundant power application is required connect to SD8XX. Voting unit. Width=35mm. DIN rail mounted. |
| 3BSC610066R1-F | SD833 | SD833 Power Supply Device Input a.c. 100-120/200-240 V, auto-select input. Output d.c. 24 V 10A. If redundant power application is required connect to SD8XX. Voting unit. Width=60mm. DIN rail mounted. |
| 3BSC610067R1-F | SD834 | SD834 Power Supply Device Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 20A. If redundant power application is required connect to SS8XX. Voting unit. Width=85mm. DIN rail mounted. |
| 3BSC610055R1-F | SS822Z | SS822Z Power Voting Unit |
| 3BSC610068R1-F | SS832 | SS832 Voting Device Input d.c. 24 V. Dual 24 V to single 24 V, 2x10A. Width=35mm. DIN rail mounted. |
| 3BSE008534R1-F | TB805 | TB805 Bus Outlet Modulebus extension cable adaptor D-sub 25, female One requried per extension cable TK801 |
| 3BSE008536R1-F | TB806 | TB806 Bus Inlet Modulebus extension cable adaptor D-sub 25, male One requried per extension cable TK801 |
| 3BSE008538R1-F | TB807 | Modulebus terminator |
| 3BSE013208R2-F | TB820V2-eA | TB820V2-eA Modulebus Cluster Modem |
| 3BSE037760R2-F | TB840A-eA | TB840A-eA Modulebus Cluster Modem |
| 3BSE022464R1-F | TB842 | TB842 Modulebus Optical Port Used together with CI801 and CI840, connected via TB806 or TB846. 10 Mbits driver. |
| 3BSE021437R1-F | TB845 | TB845, Dual Modulebus outlet Modulebus extension cable adaptor two D-sub, female. Two TK801 cables for redundancy |
| 3BSE021439R1-F | TB846 | TB846, Dual Modulebus inlet Modulebus extension cable adaptor two D-sub, male. Two TK801 cables for redundancy |
| 3BSC630197R1-F | TK212A | TK212 Tool cable RJ45 to Dsub-9 (female), length 3 m For connection of FS801 and CI840 to PC |
| 3BSC950089R1-F | TK801V003 | TK801V003 Cable. Modulebus Extension Shielded Cable 0.3m D-sub 25, male-female.G3 compliant |
| 3BSC950089R2-F | TK801V006 | TK801V006 Cable. Modulebus Extension Shielded Cable 0.6m D-sub 25, male-female. G3 compliant |
| 3BSC950089R3-F | TK801V012 | TK801V012 Cable. Modulebus Extension Shielded Cable 1.2m D-sub 25, male-female. G3 compliant. |
| 3BSC950107R1-F | TK811V015 | TK811V015 POF Cable, 1.5m, Duplex L=1.5m latching duplex connector Duplex plastic fibre |
| 3BSC950107R2-F | TK811V050 | TK811V050 POF Cable, 5m, Duplex L=5m latching duplex connector Duplex plastic fibre |
| 3BSC950107R3-F | TK811V150 | TK811V150 POF Cable, 15m, Duplex L=15m latching duplex connector Duplex plastic fibre |
| 3BSC950118R1-F | TK812V015 | TK812V015 POF Cable, 1.5m, Simplex L=1.5m latching connector Simplex plastic fibre |
| 3BSC950118R2-F | TK812V050 | TK812V050 POF Cable, 5m, Simplex L=5.0m latching connector Simplex plastic fibre |
| 3BSC950118R3-F | TK812V150 | TK812V150 POF Cable, 15m, Simplex L=15m latching connector Simplex plastic fibre |
| 3BSE035990R1-F | TU805K01 | TU805K01 Termination Units for two or three wire connection of DI801 and DO801 Include 10 pcs of Termination Unit TU805 |
| 3BSE039025R1-F | TU807 | Termination Unit for TB840/TB840A Support for single modulebus I/O. Including:1 pcs TB807 |
| 3BSE013230R1-F | TU810V1 | TU810V1 Compact Module Termination Unit, MTU, 50V. 2x8 signal terminals, rated isol. 50V. |
| 3BSE013231R1-F | TU811V1 | TU811V1 Compact Module Termination Unit, MTU, 250V. 1x8 signal terminals, rated isol. 250V. |
| 3BSE013232R1-F | TU812V1 | TU812V1 Compact Module Termination Unit, MTU, 50V. With 25 pin D-sub connector, rated isol. 50V. D-sub (female) connector is not enclosed. |
| 3BSE036714R1-F | TU813 | Compact Module Termination Unit, MTU, 250V 2x8 Signal terminals, Rated isol. 250V Detachable (pluggable) connectors are not enclosed. |
| 3BSE013233R1-F | TU814V1 | TU814V1 Compact Module Termination Unit, MTU, 50V. 2x8 Signal terminals, rated isol. 50V. Detachable (pluggable) connectors are not enclosed. |
| 3BSE069209R1-F | TU818 | TU818 Compact Module Termination Unit, MTU, 50V 1x32 (and 2x16) signal terminals, Rated isol. 50V |
| 3BSE068891R1-F | TU819 | Compact Module Termination Unit, MTU, 50V. With 2x25 pin D-sub connector, Rated isol. 50V, D-sub (female) connector is not enclosed |
| 3BSE013234R1-F | TU830V1 | TU830V1 Extended Module Termination Unit, MTU, 50V. 2x16 signal terminals, rated isol. 50V. |
| 3BSE013235R1-F | TU831V1 | TU831V1 Extended Module Termination Unit, MTU, 250V. 2x8 signal terminals, rated isol. 250V. |
| 3BSE038726R1-F | TU833 | TU833 Extended Module Termination Unit, MTU, 50V. 2x16 signal terminals, Rated isol. 50V. Spring-cage terminals. |
| 3BSE013236R1-F | TU835V1 | TU835V1 Extended Module Termination Unit, MTU, 50V. 8 fused power outlets, 8 signal terminals, rated isol. 50V. |
| 3BSE013237R1-F | TU836V1 | TU836V1 Extended Module Termination Unit, MTU, 250V. 2x4 fused signals, 2x4 return terminals, 2x2 L 2x2N terminals, rated isol. 250V. |
| 3BSE013238R1-F | TU837V1 | TU837V1 Extended Module Termination Unit, MTU, 250V. 8x1 fused isol. signals, 8x1 L terminals, 2x6 N terminals,rated isol. 250V. |
| 3BSE008572R1-F | TU838 | TU838 Extended Module Termination Unit, MTU, 50V. 2x4 fused transducer power outlets, 16 signal terminals, 2x4 return terminals, 2x2 L+, 2x2 L- terminals, rated isol. 50V. Module is mounted horizontally. |
| 3BSE046966R1-F | TU839 | TU839 Extended Module Termination Unit, 250V 2x8 signal terminals 2x4 fused sensor power Rated isol. 250V |
| 3BSE020846R1-F | TU840 | TU840 Termination Unit for 1+1 TB840 Support for redundant I/O Including: 1 pce Power Supply Connector 2 pce TB807 Modulebus Terminator |
| 3BSE020848R1-F | TU841 | Termination unit for 1+1 TB840 Support for non-redund |
| 3BSE020850R1-F | TU842 | MTU, for redundant AO/DI/DO84X, Horizontal mounted |
| 3BSE021443R1-F | TU843 | MTU, for redundant AO/DI/DO84X, Vertical mounted |
| 3BSE021445R1-F | TU844 | MTU, for redundant AI845, Horizontal mounted |
| 3BSE021447R1-F | TU845 | MTU, for redundant AI845, Vertical mounted |
| 3BSE022460R1-F | TU846 | Mounting unit for 1+1 TU847,redundant I/O |
| 3BSE022462R1-F | TU847 | Mounting unit for 1+1 TU847,non-redundant I/O |
| 3BSE042558R1-F | TU848 | TU848, MTU with individual power supply for red. TB840/TB840A. Support for dual modulebus. Including: 2 pcs TB807 |
| 3BSE042560R1-F | TU849 | TU849, MTU with individual power supply for red. TB840/TB840A. Support for single modulebus Including: 1 pcs TB807 |
| 3BSE050930R1-F | TU850 | TU850 Extended Module Termination Unit, MTU, 50V 2x8 signal terminals and 2x8 disconnetable current limited sensor/transmitter outlet power terminals. Rated isol. 50V. |
| 3BSE068782R1-F | TU851 | TU851 Extended Module Termination Unit, MTU, 250V |
| 3BSE069964R1-F | TU852 | TU852 Module Termination Unit, MTU, for redundant applications, 50V |
| 3BSE069966R1-F | TU854 | TU854 Module Termination Unit, MTU, for redundant applications, 50V |
| 3BSC690075R1-F | TU890 | TU890 Module Termination Unit for Intrinsic Safety applications 3x9 signal terminals Rated isol. 50V. Including wiring separator. |
| 3BSC840157R1-F | TU891 | TU891 Module Termination Unit for non Intrinsic Safety applications |
| 3BSE023607R1-F | TY801K01 | TY801K01 8pcs Shunt Stick TY801 125 + 125 ohms shunt. Used for AI845 and AI880 on TU844, TU845 |
| 3BSE033670R1-F | TY804K01 | TY804K01 8pcs Shunt Stick TY804 1000 ohms shunt. Used for DP840 on TU844, TU845 |
| 3BSE056980R1-F | TY820K01 | TY820K01 10pcs Temperature Sensor TY820 |
S900IO | ||
| 3KDE175512L9100 | AI910B | AI910B, Control IT Analog Input S900-AI910B eClass 27250404 transmitter power supply, 4...20 mA |
| 3KDE175513L9100 | AI910N | AI910N, Control IT Analog Input S900-AI910N (AI4)transmitter power supply, 4...20 mA |
| 3KDE175511L9100 | AI910S | AI910S, Control IT Analog Input S900-AI910S |
| 3KDE175512L9300 | AI930B | AI930B, Control IT Analog Input S900-AI930B eClass 27250404 HART, transmitter power supply, 4...20 mA |
| 3KDE175513L9300 | AI930N | AI930N, Control IT Analog Input HART S900-AI930N (AI4H)transmitter power supply, 4...20 mA |
| 3KDE175511L9300 | AI930S | AI930S, Control IT Analog Input S900-AI930S |
| 3KDE175512L9310 | AI931B | AI931B, Control IT Analog Input S900-AI931B eClass 27250404 HART, passive input, 0/4...20 mA |
| 3KDE175513L9310 | AI931N | AI931N, Control IT Analog Input HART S900-AI931N (AI4H)passive input, 0/4...20 mA |
| 3KDE175511L9310 | AI931S | AI931S, Control IT Analog Input S900-AI931S |
| 3KDE175522L9500 | AI950B | AI950B, Control IT Temperature Input S900-AI950B (TI4-B)Pt100, Pt1000, Ni100 in 2-/3-/4-wire technology, themocouples type B, E, J, K, L, N, R, S, T, isolated inputs channel by channel |
| 3KDE175523L9500 | AI950N | AI950N, Control IT Temperature Input S900-AI950N Pt100, Pt1000, Ni100 in 2-/3-/4-wire technology, themocouples type B, E, J, K, L, N, R, S, T, isolated inputs channel by channel |
| 3KDE175521L9500 | AI950S | AI950S, Control IT Temperature Input |
| 3KDE175532L9100 | AO910B | AO910B, Control IT Analog Output S900-AO910B eClass 27250404 output 0/4...20 mA |
| 3KDE175533L9100 | AO910N | AO910N, Control IT Analog Output S900-AO910N eClass 27250404 output 0/4...20 mA |
| 3KDE175531L9100 | AO910S | AO910S, Control IT Analog Output S900-AO910S |
| 3KDE175532L9200 | AO920B | AO920B, Control IT Analog Output S900-AO920B eClass 27250404 isolated, output 0/4...20 mA, isolated outputs channel by channel |
| 3KDE175533L9200 | AO920N | AO920N, Control IT Analog Output S900-AO920N eClass 27250404 isolated, output 0/4...20 mA, isolated outputs channel by channel |
| 3KDE175531L9200 | AO920S | AO920S, Control IT Analog Output S900-AO920S |
| 3KDE175532L9300 | AO930B | AO930B, Control IT Analog Output S900-AO930B eClass 27250404 HART, output 0/4...20 mA |
| 3KDE175533L9300 | AO930N | AO930N, Control IT Analog Output S900-AO930N eClass 27250404 HART, output 0/4...20 mA |
| 3KDE175531L9300 | AO930S | AO930S, Control IT Analog Output S900-AO930S |
| 3BDH000649R1 | BI914S | BI914S Fieldbus isolating repeater |
| 3KDE175831L9230 | BI923S | BI923S Ring-coupler RS485 / FO - intrinsically safe - Slave |
| 3KDE175831L9240 | BI924S | BI924S Ring-coupler RS485 / FO intrinsically safe - Master |
| 3BDH000674R0001 | BI934S | BI934S Ring-coupler RS485 / FO intrinsically safe - Slave |
| 3BSE067082R1 | BP914S | BP914S Intrinsically safe PROFIBUS-DP connector for CI920AS and CI920AB |
| 3KDE175613L2210 | CB220N | CB220N Compact-Box for power supply SA911N, communication interface CI920N and four I/O modules S900 type N (Delivery includes CD910) |
| 3KDE175839L9100 | CD910 | CD-ROM S900-CD910,S900 Documentation, Software Tools |
| 3BDH000691R1 | CI920AB | CI920AB, Communication Interface V 2.1 (CIPBA-B) |
| 3BDH000692R1 | CI920AN | CI920AN Communication Interface V 2.1 (CIPBA) |
| 3BDH000690R1 | CI920AS | CI920AS, Control IT Communication Interface S900-CI920S |
| 3KDE175322L9100 | DO910B | DO910B, Control IT Digital Output S900-DO910B eClass 27250403 output for I.S. valves |
| 3KDE175323L9100 | DO910N | DO910N, Control IT Digital Output S900-DO910N eClass 27250403 output for I.S. valves |
| 3KDE175321L9100 | DO910S | DO910S, Control IT Digital Output S900-DO910S |
| 3BDS014114 | DO930N | DO930N Relay Output (RO6) with 4 normaly-open contacts and 2 changeover contacts (only to use with CI920N Article No 3BDS014113) |
| 3KDE175362L9100 | DP910B | DP910B, Control IT Frequency Input S900-DP910B |
| 3KDE175363L9100 | DP910N | DP910N, Control IT Frequency Input S900-DP910N |
| 3KDE175361L9100 | DP910S | DP910S, Control IT Frequency Input S900-DP910S |
| 3KDE175312L9100 | DX910B | DX910B, Digital Input or Output (DIO8-B) |
| 3KDE175313L9100 | DX910N | DX910N Digital Input or Output (DIO8) |
| 3KDE175311L9100 | DX910S | DX910S, Control IT Digital Input/Output S900-DX910S |
| 3KDE175831L9200 | IP920 | IP920 Module housing |
| 3KDE175613L9110 | SA911N | SA911N Power supply for CB220N for 24 V DC the power supply filter type BP901S is not required |
| 3BDH000601R1 | SA920B | SA920B, Power Supply for 24 V DC the power supply filter type BP901S is not required SA920B is the functional replacement for SA910B do not mix SA910B with SA920B for redundancy (observe Release Notes) |
| 3BDH000600R1 | SA920N | SA920N Power Supply for 24 V DC the power supply filter type BP901S is not required SA920N is the functional replacement for SA910N do not mix SA910N with SA920N for redundancy (observe Release Notes) |
| 3BDH000602R1 | SA920S | SA920S,SA920S Power Supply for 24 V DC the power supply filter type BP901S is not required SA920S is the functional replacement for SA910S do not mix SA910S with SA920S for redundancy (observe Release Notes) |
| 3KDE175112L9210 | TU921B | TU921B, Control IT Redundant Termination Unit S900-TU921B |
| 3KDE175113L9210 | TU921N | TU921N, Control IT Redundant Termination Unit S900-TU921N eClass 27250415 for 16 I/O modules, redundant communication and power |
| 3KDE175111L9210 | TU921S | TU921S, Control IT Redundant Termination Unit S900-TU921S eClass 27250415 for 16 I/O modules, redundant communication and power |
| Operator Panel Panel V5 | ||
| 3BSE042245R1 | CB801 | CB801 PROFIBUS DP Communication Interface PROFIBUS DP slave expansion module for Panel 800. |
| 3BSE042255R1 | CB810 | CB810 USB to Ethernet adapter for programming USB to Ethernet adapter with software Cross over Ethernet patch cable included |
| 3BSE042257R1 | MB801V512 | MB801V512 Compact Flash card Industrial Grade, 512 MB |
| 3BSE042250R1 | Panel builder 800 version 5 | Panel builder 800 version 5 |
| 3BSE042239R2 | PP815A | Panel 800 - PP815 A 3.8" Touch panel TFT 320x240 pixels, graphics & text, touch, color |
| 3BSE042243R2 | PP820A | Panel 800 - PP820 A Key panel 240x64 pixels, graphics & text, key, black/white |
| 3BSE042240R3 | PP825A | Panel 800 - PP825 A 5,7" Touch panel STN 320x240 pixels, graphics & text, touch, color To protect the touch screen, it's recommended to use the RX825 Touch Cover |
| 3BSE042244R3 | PP826A | Panel 800 - PP826 A 5,7" Key panel STN 320x240 pixels, graphics & text, color |
| 3BSE042234R2 | PP835A | Panel 800 - PP835 A 6.5" Touch panel TFT 640x480 pixels, graphics & text, touch, color To protect the touch screen, it's recommended to use the RX835 Touch Cover |
| 3BSE042237R2 | PP836A | Panel 800 - PP836 A 6.5" Function key panel TFT 640x480 pixels, graphics & text, color |
| 3BSE042235R2 | PP845A | Panel 800 - PP845 A 10.4" Touch panel TFT 800x600 pixels, graphics & text, touch, color To protect the touch screen, it's recommended to use the RX845 Touch Cover |
| 3BSE042238R2 | PP846A | Panel 800 -PP846A 10.4" Function key panel TFT 800x600 pixels, graphics & text, color |
| 3BSE042236R2 | PP865A | Panel 800 - PP865 A 15" Touch panel TFT 1024x768 pixels, graphics & text, touch, color To protect the touch screen, it's recommended to use the RX865 Touch Cover |
| 3BSE049366R1 | RX815 | RX815 Touch cover for PP815/PP815A, 1 pcs |
| 3BSE049367R1 | RX820 | RX820 Key cover for PP820/PP820A, 1 pcs |
| 3BSE042246R1 | RX825 | RX825 Touch cover for PP825/PP825A, 1 pcs |
| 3BSE049368R1 | RX826 | RX826 Key cover for PP826/PP826A, 1 pcs |
| 3BSE042247R1 | RX835 | RX835 Touch cover for PP835, 1 pcs |
| 3BSE049369R1 | RX836 | RX836 Key cover for PP836/PP836A, 1 pcs |
| 3BSE042248R1 | RX845 | RX845 Touch cover for PP845, 1 pcs |
| 3BSE049370R1 | RX846 | RX846 Key cover for PP846/PP846A, 1 pcs |
| 3BSE042249R1 | RX865 | RX865 Touch cover for PP865, 1 pcs |
| 3BSE042251R1 | TK854V030 | RS232 programming cable Panel 800 <--> PC Length 3 m |
Panel V6 | ||
| 3BSE069477R1 | MB802V2 SD card 2GB | MB802V2 SD card 2GB Secure Digital memory card 2GB Industrial grade for Version 6 panels. |
| 3BSE069300R1 | Panel Builder 800 version 6, incl license | Panel builder 800 version 5 |
| 3BSE069270R1 | PP871 | Panel 800 -PP871 4,3" Touch panel TFT 480x272 (16:9) Requires Panel Builder 800 Version 6 for configuration. |
| 3BSE069271R1 | PP874 | Panel 800 -PP874 7" Touch panel TFT 800x480 (16:9) Requires Panel Builder 800 Version 6 for configuration. |
| 3BSE069272R1 | PP877 | Panel 800 -PP877 10,4" Touch panel TFT 640x480 (4:3) Requires Panel Builder 800 Version 6 for configuration. |
| 3BSE069275R1 | PP882 | PP882 High performance touch panel 12.1" |
| 3BSE069276R1 | PP885 | PP885 High performance touch panel 15.4" |
| 3BSE069286R1 | RX871 | RX871 Touch cover for PP871 |
| 3BSE069287R1 | RX874 | RX874 Touch cover for PP874 |
| 3BSE069288R1 | RX877 | RX877 Touch cover for PP877 |
| 3BSE069291R1 | RX882 | RX882 Touch cover for PP882 |
| 3BSE069292R1 | RX885/893 | RX885/893 Touch cover for PP885/893 |
| 3BSE069474R1 | TK858V002 | TK858V002 Adapter cable (CAB 107, TK855V002) |
| 3BSE069475R1 | TK859V000 | TK859V000 Gender changer (TK856V000) |
| 3BSE069476R1 | TK860V001 | TK860V001 Splitter cable (CAB 109, TK857V001) |
ABB ACS150 APPLICATIONAcs150 has a wide power range and a wide range o...
Our rich industry experience and complete product range will help your...
BU4493 800xA 800xA V5.13BSE061262R110 Additional Batch Equipment, 800x...
Medium voltage variable speed drive from 315 to 16,200KVAPart of Altiv...
Keep up on our always evolving product features and technology. Enter your e-mail and subscribe to our newsletter.
