Schneider Electric Modicon M580 ePAC: Features & Performance

The Schneider Electric Modicon M580 ePAC redefines industrial automation control with superior performance and flexible architecture. As the industry's first "Electronic-to-the-end" programmable automation controller, it represents the future of control systems. This series features an embedded dual-core microprocessor architecture, offering outstanding processing power. The BMEP583040 processor executes 15K instructions per millisecond, while the redundant BMEH584040 processor doubles that to 30K instructions per millisecond, supporting complex industrial applications.

The M580’s hardware uses an ARM multi-core processor and dual-bus backplane technology, balancing responsiveness with data bandwidth. It integrates 12MB program memory, 1024KB data memory, and supports up to 4GB of expandable flash. The redundant processor enhances performance further, with 16MB program memory and 2048KB data memory.

Modicon M580 Security & Communication Features

The M580 series includes standard, redundant processors, and security controllers, providing high reliability with up to 64 device connections. Security features meet IEC 62443/ISA 99 standards and include firewalls, DoS protection, IPSec encryption, and password protection. The Modicon M580 Safety ePAC, with dual-security architecture, ensures secure data handling, vital for applications with high security demands.

The system's communication relies on industrial Ethernet and supports up to eight communication modules, including Ethernet TCP/IP and USB ports. This flexibility allows the M580 to build complex, reliable network topologies across various industrial applications.

Performance & I/O Support of Modicon M580 ePAC

The M580 ePAC excels in local I/O processing, supporting up to 3072 discrete I/Os and 768 analog I/Os, with scalability to 8192 discrete I/Os and 2048 analog I/Os with the redundant processor. Its Mean Time Between Failures (MTBF) of 650,000 hours ensures system reliability.

The controller supports advanced functions like HART protocol, SSI encoder, motion control, and precise timestamps, addressing the needs of diverse applications. Designed for rugged environments, it features IP20 protection, vibration resistance, and a wide temperature range, making it suitable for industrial operations in extreme conditions.

Modicon M580 for Industrial Automation

The Modicon M580 ePAC series offers robust automation control solutions, helping industries achieve reliable and efficient digital transformation. With its advanced features, superior security, and scalable I/O support, it ensures long-term operational stability, providing a competitive edge in complex industrial environments.
